- Basic Specifications - EAN
- 4711387710302
- Basic Specifications - Manufacturer's Part Number
- 125648
- External connectivity - Audio
- Audio jacks x 2
- External connectivity - LAN
- - Intel® 2.5Gb Ethernet x 1- Realtek 5Gb Ethernet x 1- ASUS LANGuard
- External connectivity - Other external connections
- - HDMI™ port x 1- Wi-Fi module x 1- Intel® 2.5Gb Ethernet port x 1- Realtek 5Gb Ethernet port x 1- Gold-plated audio jacks x 2- Optical S/PDIF out port x 1- BIOS FlashBack™ button x 1- Clear CMOS button x 1
- External connectivity - USB
- - USB Type-C x 6- USB 3.0 x 10- USB 2.0 x 4
- External connectivity - Video output
- - HDMI 2.1 x 1- USB Type-C x 2
- General - Box contents
- - Asus ROG STRIX X870E-E WiFi AMD AM5 Motherboard- Cables- ARGB RGB extension cable x 1- SATA 6Gb/s cables x 4- ASUS WiFi Q-Antenna x 1- Q-connector x 1- M.2 Q-Latch package x 2- M.2 Q-Slide package x 3- M.2 rubber package x 5- ROG stickers x 1- ROG thank you card x 1- ROG Bottle Opener x 1- USB drive with utilities and drivers x 1- Quick start guide x 1
- General - Colour
- Black
- General - Dimensions
- 25 x 244 x 305 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Software included
- - ROG CPU-Z- Dolby Atmos- Internet Security (1-year full version)- Polymo Lighting IIASUS Exclusive Software Armoury Crate- AIDA64 Extreme (1 year full version) - Aura Creator- Aura Sync-Fan Xpert 4 (with AI Cooling II)- GameFirst- HWiNFO- Power Saving- ASUS DriverHub- ASUS GlideX- USB Wattage Watcher- TurboV Core - WinRAR (40 Days Free Trial)- Adobe Creative Cloud (Free Trial)- UEFI BIOS- AI Overclocking Guide- ASUS EZ DIY- ASUS CrashFree BIOS 3 - ASUS EZ Flash 3- ASUS UEFI BIOS EZ Mode- ASUS MyHotkey- FlexKey
- General - Weight
- 2.63 kg
- Internal connectivity - BIOS
- - 256 Mb Flash ROM- UEFI AMI BIOS
- Internal connectivity - Buttons
- - Power- Reset- BIOS FlashBack- FlexKey- Clear CMOS
- Internal connectivity - Case
- - Power LED x 1- Clear CMOS header x 1
- Internal connectivity - Cooling
- - CPU fan header 4-pin x 1- CPU OPT fan header 4-pin x 1- AIO Pump header 4-pin x 1- Chassis fan headers 4-pin x 4- W_PUMP+ header x 1
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16 Slots) x 2- PCIe 4.0 (x16 Slots) x 4
- Internal connectivity - Other internal connections
- - Addressable Gen2 headers x 3- Alteration PCIe mode switch x 1- FlexKey button x 1- Front Panel Audio header (F_AUDIO) x 1- ReTry button x 1- Start button x 1- 10-1 pin System Panel header x 1- Thermal Sensor header x 1- LN2 Mode jumper x 1
- Internal connectivity - Power
- - 24-pin EATX x 1- 8-pin ATX 12 V x 2- 6-pin PCIe x 1
- Internal connectivity - Sensors
- Thermal sensor header x 1
- Internal connectivity - Storage slots
- - SATA x 4 (6 GB/s)- M.2 x 5
- Internal connectivity - USB
- - USB Type-C x 1- USB 3.2 x 2- USB 2.0 x 3
- Overview - Chipset
- AMD X870E
- Overview - Form factor
- ATX
- Overview - Memory slots
- 4 x DIMM (Max RAM: 192 GB)
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- Windows 11
- Overview - Processor models supported
- AMD RYZEN 7000 / 8000 / 8600 / 8500 / 8400 / 8300 / 9000 Series desktop processors
- Overview - Socket
- AMD AM5
