- Basic Specifications - EAN
- 4711387747223
- Basic Specifications - Manufacturer's Part Number
- 125805
- External connectivity - Audio
- Audio jacks x 2
- External connectivity - LAN
- - Intel® 2.5Gb Ethernet port x 1- 1 x Realtek 5Gb Ethernet port x 1
- External connectivity - Other external connections
- - WiFi module x 1- S/PDIF x 1
- External connectivity - USB
- - Thunderbolt 4 x 2- USB Type-C x 1- USB 3.0 x 18
- External connectivity - Video output
- - HDMI 2.1 x 1- DisplayPort 2.1 x 1
- General - Box contents
- - Asus ROG MAXIMUS WiFi Z890 Hero LGA1851 Motherboard- ARGB RGB extension cable x 1- SATA 6Gb/s cables x 4- Additional Cooling Kit x 1- DDR5 fan holder x 1- Thermal pad for M.2 22110 x 1- ASUS WiFi Q-Antenna x 1- Q-connector x 1- M.2 Q-Latch package x 1- M.2 Q-Slide packages x 3- ROG stickers x 1- M.2 rubber packages x 6- ROG thank you card x 1- ROG Bottle Opener x 1- Installation Media- USB drive with utilities and drivers x 1- Documentation- Quick start guide
- General - Colour
- Black
- General - Dimensions
- 50 x 244 x 305 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Software included
- - ROG Exclusive Software- ROG CPU-Z- Dolby Atmos- Internet Security (1-year full version)- ASUS Exclusive Software- Armoury Crate- AIDA64 Extreme (1 year full version)- Aura Creator- Aura Sync- Fan Xpert 4 (with AI Cooling II)- GameFirst- HWiNFO- Power Saving- LCD Display- ASUS AI Advisor- ASUS Driver Hub- Turbo Vcore- ASUS GlideX- Thunderbolt™ Share- USB Wattage Watcher- WinRAR (40 Days Free Trial)- Adobe Creative Cloud (Free Trial)- UEFI BIOS- AI Overclocking Guide- NPU Boost- ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode- ASUS MyHotkey
- General - Weight
- 2.72 kg
- Internal connectivity - BIOS
- - UEFI AMI BIOS- Flash ROM (256 MB)
- Internal connectivity - Buttons
- - Power- Clear CMOS- BIOS FlashBack- FlexKey button
- Internal connectivity - Case
- QLED x 1
- Internal connectivity - Cooling
- - 4-pin CPU fan header x 1- 4-pin CPU OPT fan header x 1- 4-pin AIO pump header x 1- 4-pin chassis fan headers x 1- W_PUMP+ headers x 1
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16) x 1- PCIe 4.0 (x16) (support x 4 mode) x 1- PCIe 4.0 (x1) x 1
- Internal connectivity - Other internal connections
- - Front Panel Audio header x 1- 10-1 pin System Panel header x 1- Thunderbolt (USB4) header x 1
- Internal connectivity - Power
- - 24-pin main power x 1- 8-pin 12 V power x 2- 8-pin PCIe Power connector x 1
- Internal connectivity - Sensors
- Thermal sensor header x 1
- Internal connectivity - Storage slots
- - SATA x 4 (6 GB/s)- M.2 x 6
- Internal connectivity - USB
- - USB Type-C x 2- USB 3.0 x 2- USB 2.0 x 2
- Overview - Chipset
- Intel® Z890
- Overview - Cooling features
- - Xpert 4 (with AI Cooling II)- Fan cooling
- Overview - Form factor
- ATX
- Overview - Memory slots
- 4 x DIMM (Max RAM: 192 GB)
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- Windows 11
- Overview - Processor models supported
- Intel® Core™ Ultra Processors (series 2)
- Overview - Socket
- Intel® LGA1851
