- Aerial - Aerial
- External detachable
- Aerial - Antenna Qty
- 2
- Basic Specifications - Capacity
- VLANs supported: 16 ¦ Concurrent VPN tunnels: 32 ¦ NAT sessions: 60000 ¦ Concurrent SSL VPN tunnels: 16
- Basic Specifications - Compliant Standards
- IEEE 802.1Q, ANSI T1.413, IEEE 802.1p, IEEE 802.1x, UPnP
- Basic Specifications - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, PPP, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- Basic Specifications - Device Type
- Wireless router - DSL modem - 6-port switch (integrated)
- Basic Specifications - Digital Signaling Protocol
- ADSL, VDSL, ADSL2, ADSL2+, VDSL2, Vplus 35b
- Basic Specifications - Dimensions (WxDxH)
- 24.1 cm x 16.5 cm x 4.4 cm
- Basic Specifications - EAN
- 4710484743862
- Basic Specifications - Enclosure Type
- Desktop, wall-mountable
- Basic Specifications - Features
- Firewall protection, NAT support, VPN support, ARP support, load balancing, IGMP snooping, Syslog support, DoS attack prevention, ALG support, port mirroring, E-mail alert, High Availability, WDS support, URL filtering, firmware upgradable, MIMO technology, LAN-to-LAN bridging, WMM support, file sharing, ACL support, IPSec NAT-T, DHCP server, Multiple SSID support, SMS alert, reset button, bandwidth control, DNS server, port triggering, SPIF, 3G/4G USB Dongle Support, anti-spoofing protection, IP-MAC binding, application filtering, tagged VLAN, IGMP proxy, cloud managed, GRE, ToS, DSCP support, MU-MIMO technology, keyword filtering, band steering, failover protection, Web Filtering, policy based routing, Airtime Fairness, client isolation, DMZ support, VLAN Tagging, port-based VLAN, DSCP based ToS, multiple PVC support, DynDNS, WLAN scheduling, WPS button, OpenVPN pass-through, Brute Force Protection
- Basic Specifications - Frequency Band
- 2.4 GHz / 5 GHz
- Basic Specifications - Localisation
- United Kingdom, Ireland
- Basic Specifications - Manufacturer Warranty
- 2-year warranty
- Basic Specifications - Manufacturer's Part Number
- V2865AX-K
- Basic Specifications - Model
- Draytek Vigor 2865ax
- Basic Specifications - Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, DHCP, DNS, Bonjour, DDNS
- Basic Specifications - Performance
- VPN throughput (256-bit AES IPSec): 300 Mbps ¦ VPN throughput (SSL): 130 Mbps ¦ NAT throughput: 800 Mbps
- Basic Specifications - Product Description
- Draytek Vigor 2865ax - wireless router - DSL modem - Wi-Fi 6 - desktop, wall-mountable
- Basic Specifications - Remote Management Protocol
- SNMP 2, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, TR-069, TR-104
- Basic Specifications - Routing Protocol
- RIP, BGP, GRE, static IPv4 routing, static IPv6 routing, policy-based routing (PBR)
- Basic Specifications - VoIP Protocols
- H.323, SIP
- Basic Specifications - WAN Ports Qty
- 2
- Basic Specifications - Weight
- 780 g
- Communications - Digital Signaling Protocol
- ADSL, VDSL, ADSL2, ADSL2+, VDSL2, Vplus 35b
- Communications - Max Transfer Rate
- 300 Mbps
- Communications - Protocols & Specifications
- ITU G.992.1 (G.DMT), ITU G.992.3 Annex A, ITU G.993.2, ITU G.992.5 Annex A, ITU G.993.5
- Communications - Type
- DSL modem
- Dimensions & Weight - Depth
- 16.5 cm
- Dimensions & Weight - Height
- 4.4 cm
- Dimensions & Weight - Weight
- 780 g
- Dimensions & Weight - Width
- 24.1 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 90% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 45 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Interfaces
- LAN: 5 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 1 x VDSL2 / ADSL2+ - RJ-11 ¦ USB 2.0: 2 x 4 pin USB Type A
- General - Authentication Method
- RADIUS, X.509 certificates, TACACS+, LDAP, internal user database, XAUTH authentication
- General - Built-in Devices
- Led panel
- General - Capacity
- VLANs supported: 16 ¦ Concurrent VPN tunnels: 32 ¦ NAT sessions: 60000 ¦ Concurrent SSL VPN tunnels: 16
- General - Compliant Standards
- IEEE 802.1Q, ANSI T1.413, IEEE 802.1p, IEEE 802.1x, UPnP
- General - Connectivity Technology
- Wireless, wired
- General - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, PPP, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- General - Device Type
- Wireless router - 6-port switch (integrated)
- General - Enclosure Type
- Desktop, wall-mountable
- General - Encryption Algorithm
- DES, Triple DES, MPPE, AES, SSL, SHA-1, IKEv2, 256-bit SHA
- General - Features
- Firewall protection, NAT support, VPN support, ARP support, load balancing, IGMP snooping, Syslog support, DoS attack prevention, ALG support, port mirroring, E-mail alert, High Availability, WDS support, URL filtering, firmware upgradable, MIMO technology, LAN-to-LAN bridging, WMM support, file sharing, ACL support, IPSec NAT-T, DHCP server, Multiple SSID support, SMS alert, reset button, bandwidth control, DNS server, port triggering, SPIF, 3G/4G USB Dongle Support, anti-spoofing protection, IP-MAC binding, application filtering, tagged VLAN, IGMP proxy, cloud managed, GRE, ToS, DSCP support, MU-MIMO technology, keyword filtering, band steering, failover protection, Web Filtering, policy based routing, Airtime Fairness, client isolation, DMZ support, VLAN Tagging, port-based VLAN, DSCP based ToS, multiple PVC support, DynDNS, WLAN scheduling, WPS button, OpenVPN pass-through, Brute Force Protection
- General - Frequency Band
- 2.4 GHz / 5 GHz
- General - Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, DHCP, DNS, Bonjour, DDNS
- General - Performance
- VPN throughput (256-bit AES IPSec): 300 Mbps ¦ VPN throughput (SSL): 130 Mbps ¦ NAT throughput: 800 Mbps
- General - Remote Management Protocol
- SNMP 2, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, TFTP, SSH, CLI, TR-069, TR-104
- General - Routing Protocol
- RIP, BGP, GRE, static IPv4 routing, static IPv6 routing, policy-based routing (PBR)
- General - Status Indicators
- WAN, DMZ, link/activity, USB, VPN, DSL
- General - Wi-Fi Rating
- AX3000
- IP Telephony - VoIP Protocols
- H.323, SIP
- Line Properties - Framing Format
- ANSI T1.413
- Manufacturer Warranty - Service & Support
- Limited warranty - 2 years
- Miscellaneous - Cables Included
- 1 x network cable - 2 m
- Miscellaneous - Included Accessories
- 2 aerials
- Miscellaneous - Localisation
- United Kingdom, Ireland
- Power - Power Device
- External power adapter
- Software / System Requirements - OS Provided
- No operating system
