- Basic Specifications - Batteries Qty
- 6
- Basic Specifications - Battery
- Lead Acid expandable - 9 Ah
- Basic Specifications - Colour
- Black, silver
- Basic Specifications - Device Type
- UPS - rack-mountable / external
- Basic Specifications - Dimensions (WxDxH)
- 44 cm x 60.5 cm x 8.65 cm
- Basic Specifications - EAN
- 3553340620287
- Basic Specifications - Environmental Standards
- ENERGY STAR
- Basic Specifications - Included Accessories
- Tower stand
- Basic Specifications - Input Connectors
- 1 x power BS
- Basic Specifications - Input Voltage
- AC 200/208/220/230/240 V
- Basic Specifications - Input Wiring
- 1-phase
- Basic Specifications - Manufacturer Warranty
- 3-year warranty
- Basic Specifications - Manufacturer's Part Number
- 9PX3000IRTNBS
- Basic Specifications - Networking
- Ethernet 10/100, RS-232, USB
- Basic Specifications - Output connectors
- 8 x power IEC 60320 C13 ¦ 2 x power IEC 60320 C19
- Basic Specifications - Output Voltage
- AC 200/208/220/230/240 V ± 1%
- Basic Specifications - Power Capacity
- 3000 Watt / 3000 VA
- Basic Specifications - Product Description
- Eaton 9PX - Netpack - UPS - 3000 Watt - 3000 VA
- Basic Specifications - Product Type
- UPS
- Basic Specifications - Rack Size
- 19" - 2U
- Basic Specifications - Remote Management Protocol
- Telnet, SNMP 3, HTTP, SSH, CLI, SMTP, DHCP, IPv6
- Basic Specifications - Run Time (Up To)
- 3 min at full load
- Basic Specifications - Weight
- 28.143 kg
- Battery - Capacity
- 9 Ah
- Battery - Features
- Sealed
- Battery - Quantity
- 6
- Battery - Run Time (Up To)
- 3 min at full load ¦ 60 min at 300 Watts ¦ 36 min at 500 Watts ¦ 22 min at 800 Watts ¦ 13 min at 1200 Watts ¦ 7 min at 1800 Watts ¦ 4 min at 2500 Watts
- Battery - Technology
- Lead Acid
- Battery - Type
- Expandable
- Battery - Voltage Provided
- 12 V
- Dimensions & Weight - Depth
- 60.5 cm
- Dimensions & Weight - Height
- 8.65 cm
- Dimensions & Weight - Weight
- 28.143 kg
- Dimensions & Weight - Width
- 44 cm
- Environmental Parameters - Humidity Range Operating
- 0 - 96% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 40 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Environmental Parameters - Sound Emission
- 40 dB
- Environmental Standards - ENERGY STAR
- Yes
- Expansion / Connectivity - Expansion Slots
- 1 (total) / 0 (free) x Expansion Slot
- Expansion / Connectivity - Interfaces
- 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B ¦ 1 x remote power (on/off) - mini terminal block ¦ 1 x remote power off - mini terminal block ¦ 1 x relay output - mini terminal block ¦ 1 x management (Fast Ethernet) - RJ-45 ¦ 1 x RS-232 / sensor - RJ-45
- General - Colour
- Black, silver
- General - Device Type
- UPS - rack-mountable / external
- General - Height (Rack Units)
- 2U
- General - Rack Size
- 19"
- Manufacturer Warranty - Service & Support
- Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years
- Miscellaneous - Cables Included
- 2 x power cable - external ¦ USB cable - external ¦ Serial cable - external ¦ Power cable - external - 1.8 m
- Miscellaneous - Compliant Standards
- TUV, CISPR 22 Class B, UL 1778, CB, IEC 62040-2, cULus, CSA 22.2, KC, EN 62040-2, EAC, RCM, IEC 62040-1, EN 62040-1, FCC Part 15 Class B
- Miscellaneous - Features
- Advance Battery Management (ABM), LCD display, internal bypass, deep discharge protection, automatic shut down, automatic self-test, hot-swappable batteries, double conversion
- Miscellaneous - Included Accessories
- Tower stand
- Miscellaneous - Rack Mounting Kit
- Included
- Networking - Remote Management Interface
- Ethernet 10/100, RS-232, USB
- Networking - Remote Management Protocol
- Telnet, SNMP 3, HTTP, SSH, CLI, SMTP, DHCP, IPv6
- Power Device - Efficiency
- 98% Eco mode, 94% online mode
- Power Device - Frequency Provided
- 50/60 Hz
- Power Device - Frequency Required
- 40 - 70 Hz
- Power Device - Input Connectors
- 1 x power BS
- Power Device - Input Voltage
- AC 200/208/220/230/240 V
- Power Device - Input Voltage Range
- AC 100 - 276 V
- Power Device - Input Wiring
- 1-phase
- Power Device - Output Voltage
- AC 200/208/220/230/240 V ± 1% - 50/60 Hz
- Power Device - Output Waveform
- Sinewave
- Power Device - Power Capacity
- 3000 Watt / 3000 VA
- Power Device - Power Factor (PF)
- 0.99
- Power Device - Power Output Connectors Details
- 8 x power IEC 60320 C13 ¦ 2 x power IEC 60320 C19
- Power Device - UPS Technology
- On-line
- Sustainability Information - ENERGY STAR
- Yes
