- Basic Specifications - EAN
- 4711387740309
- Basic Specifications - Manufacturer's Part Number
- 125654
- External connectivity - Audio
- Audio jacks x 1
- External connectivity - LAN
- - Intel 2.5Gb Ethernet x 1- ASUS LANGuard
- External connectivity - Other external connections
- - HDMI port x 1- Wi-Fi module x 1- Intel 2.5Gb Ethernet port x 1- BIOS FlashBack button x 1- Clear CMOS button x 1
- External connectivity - USB
- - USB4 (40 Gbps)(2 x USB Type-C) x 2- USB 10Gbps ports (4 x Type-A + 1 x USB Type-C, 1 port supports ROG STRIX HIVE II) x 5- USB 2.0 ports (2 x Type-A) x 3
- External connectivity - Video output
- - HDMI x 1- DisplayPort x 1
- General - Box contents
- - Asus ROG STRIX Gaming WiFi X870-I AM5 Motherboard- Cables- Panel cable x 1- ROG USB2.0 splitter cable x 1- SATA 6Gb/s cables x 2ROG FPS Card1 x ROG FPS Card x 1ROG STRIX HIVE II- ROG STRIX HIVE II x 1- USB Type-C power connection cable x 1- ASUS WiFi Q-Antenna x 1- Cable ties package x 1- M.2 Q-Latch package x 1- ROG key chain x 1- ROG Strix stickers x 1- M.2 rubber package x 1- Quick start guide x 1
- General - Colour
- Black
- General - Dimensions
- 25 x 170 x 170 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Software included
- ROG Exclusive Software- ROG CPU-Z- Dolby AtmosASUS Exclusive SoftwareArmoury Crate- AIDA64 (60 days free trial) - Aura Creator- Aura Sync- Fan Xpert 4 (with AI Cooling II)- GameFirst- HWiNFO- Power Saving- ASUS Driver Hub- ASUS GlideX- Adobe Creative Cloud (Free Trial)- Norton 360 for Gamers (60 Days Free Trial)- WinRAR (40 Days Free Trial)UEFI BIOSAI Overclocking GuideASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFIBIOS EZ Mode- ASUSMyHotkeyFlexKeyDynamic OC Switcher
- General - Weight
- 1.05 kg
- Internal connectivity - BIOS
- - 256 Mb Flash ROM- UEFI AMI BIOS
- Internal connectivity - Buttons
- - BIOS FlashBack button x 1- Clear CMOS button x 1
- Internal connectivity - Case
- - Power LED x 1- Clear CMOS header x 1
- Internal connectivity - Cooling
- - 4-pin CPU fan header x 1- 4-pin AIO Pump header x 1- 4-pin chassis fan headers x 1
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16) (supports x16 mode) x 1- PCIe 4.0 (x16) (support x8 / x4 mode) x 1
- Internal connectivity - Other internal connections
- - Addressable Gen 2 headers x 2- 2-pin Power Button header x 1- Thermal Sensor header x 1- USB Type-C connectors to install ROG FPS card x 2
- Internal connectivity - Power
- - 24-pin EATX x 1- 8-pin ATX 12 V x 1
- Internal connectivity - Sensors
- Thermal sensor header
- Internal connectivity - Storage slots
- - SATA x 2 (6 GB/s)- M.2 x 2
- Internal connectivity - USB
- - USB 10Gbps connector (supports USB Type-C) x 1- USB 5Gbps header (supports 2 additional USB 5Gbps ports) x 1
- Overview - Chipset
- AMD X870
- Overview - Form factor
- mini ITX
- Overview - Memory slots
- DIMM (Max RAM: 96 GB) x 2
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- Windows 11
- Overview - Processor models supported
- AMD RYZEN 7000 / 8000 / 9000 processors
- Overview - Socket
- AMD AM5
