- Basic Specifications - Capacity
- IGMP groups: 512 ¦ MLD groups: 256 ¦ VLAN groups: 4000 ¦ Static ARP entries: 256
- Basic Specifications - Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z, IEEE 802.1AX, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1p, IEEE 802.1Qbb, IEEE 802.3af, IEEE 802.3at
- Basic Specifications - Device Type
- Switch - 52 ports - L3 - smart - stackable
- Basic Specifications - Dimensions (WxDxH)
- 44.1 cm x 30.85 cm x 4.4 cm
- Basic Specifications - EAN
- 0790069454806
- Basic Specifications - Enclosure Type
- Rack-mountable 1U
- Basic Specifications - Features
- ZTP, RSPAN, ERPS, DNA support, VRRP support, MDI, MDI-X, Link Aggregation, STP support, BPDU Filter, Loop Guard, MSTP support, Rapid Reconfiguration of Spanning Tree (RSTP), Root Guard, flow mirroring, loopback detection, port mirroring, VLAN mirroring, ERPS v2, IGMP snooping, GVRP, Private VLAN, VLAN trunking, Voice VLAN, OSPF, QoS, WDRR, WRED, WRR, CoS, BPDU, DoS, EEE, D-Link DDP, NTP 3, NTP 4, store and forward
- Basic Specifications - Jumbo Frame Support
- 12288 bytes
- Basic Specifications - MAC Address Table Size
- 16384 entries
- Basic Specifications - Manufacturer's Part Number
- DGS-1520-52MP
- Basic Specifications - Model
- D-Link DGS 1520-52MP
- Basic Specifications - Performance
- Switching capacity: 188 Gbps ¦ Forwarding performance: 139.88 Mpps ¦ Stacking bandwidth: 80 Gbps
- Basic Specifications - PoE Budget
- 370 W
- Basic Specifications - Ports
- 44 x 10/100/1000 (PoE+) + 4 x 2.5GBase-T (PoE+) + 2 x 10 Gigabit Ethernet + 2 x 10 Gigabit SFP+
- Basic Specifications - Power
- AC 120/230 V (50/60 Hz)
- Basic Specifications - Power Over Ethernet (PoE)
- PoE+
- Basic Specifications - Product Description
- D-Link DGS 1520-52MP - switch - 52 ports - smart - rack-mountable
- Basic Specifications - Remote Management Protocol
- SNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9
- Basic Specifications - Routing Protocol
- IGMP, IGMPv2, IGMPv3, MLD, MLDv2, PIM-DM, PIM-SM, PIM-SSM, static IP routing, OSPF, RIPng, ECMP, RIP-1, RIP-2, policy-based routing (PBR), DVMRP
- Basic Specifications - Subtype
- Gigabit Ethernet
- Basic Specifications - Weight
- 4.8 kg
- Dimensions & Weight - Depth
- 30.85 cm
- Dimensions & Weight - Height
- 4.4 cm
- Dimensions & Weight - Weight
- 4.8 kg
- Dimensions & Weight - Width
- 44.1 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 95% (non-condensing)
- Environmental Parameters - Humidity Range Storage
- 5 - 95% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 50 °C
- Environmental Parameters - Max Storage Temperature
- 70 °C
- Environmental Parameters - Min Operating Temperature
- -5 °C
- Environmental Parameters - Min Storage Temperature
- -40 °C
- Expansion / Connectivity - Interfaces
- 44 x 1000Base-T RJ-45 PoE+ ¦ 4 x 2.5GBase-T RJ-45 PoE+ ¦ 2 x 10GBase-T RJ-45 ¦ 2 x 10GBase-X SFP+
- General - Authentication Method
- Secure Shell v.2 (SSH2), RADIUS, TACACS+
- General - Capacity
- IGMP groups: 512 ¦ MLD groups: 256 ¦ VLAN groups: 4000 ¦ Static ARP entries: 256
- General - Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z, IEEE 802.1AX, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1s, IEEE 802.1w, IEEE 802.1Q, IEEE 802.1v, IEEE 802.1p, IEEE 802.1Qbb, IEEE 802.3af, IEEE 802.3at
- General - Device Type
- Switch - 52 ports - L3 - smart - stackable
- General - Enclosure Type
- Rack-mountable 1U
- General - Encryption Algorithm
- TLS 1.0, TLS 1.1, TLS 1.2, SSL
- General - Features
- ZTP, RSPAN, ERPS, DNA support, VRRP support, MDI, MDI-X, Link Aggregation, STP support, BPDU Filter, Loop Guard, MSTP support, Rapid Reconfiguration of Spanning Tree (RSTP), Root Guard, flow mirroring, loopback detection, port mirroring, VLAN mirroring, ERPS v2, IGMP snooping, GVRP, Private VLAN, VLAN trunking, Voice VLAN, OSPF, QoS, WDRR, WRED, WRR, CoS, BPDU, DoS, EEE, D-Link DDP, NTP 3, NTP 4, store and forward
- General - Jumbo Frame Support
- 12288 bytes
- General - MAC Address Table Size
- 16384 entries
- General - Max Units In A Stack
- 8
- General - Performance
- Switching capacity: 188 Gbps ¦ Forwarding performance: 139.88 Mpps ¦ Stacking bandwidth: 80 Gbps
- General - PoE Budget
- 370 W
- General - Ports
- 44 x 10/100/1000 (PoE+) + 4 x 2.5GBase-T (PoE+) + 2 x 10 Gigabit Ethernet + 2 x 10 Gigabit SFP+
- General - Power Over Ethernet (PoE)
- PoE+
- General - Remote Management Protocol
- SNMP 1, SNMP 2c, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9
- General - Routing Protocol
- IGMP, IGMPv2, IGMPv3, MLD, MLDv2, PIM-DM, PIM-SM, PIM-SSM, static IP routing, OSPF, RIPng, ECMP, RIP-1, RIP-2, policy-based routing (PBR), DVMRP
- General - Status Indicators
- Power, stack, fan, link/activity, PoE
- General - Subtype
- Gigabit Ethernet
- Miscellaneous - Compliant Standards
- FCC Class A certified, IC Class A, RCM Class A, VCCI Class A, BSMI Class A
- Miscellaneous - MTBF
- 328174 hours
- Power - Power Consumption Operational
- 459.5 Watt
- Power - Power Device
- Internal power supply
- Power - Voltage Required
- AC 120/230 V (50/60 Hz)
