- Aerial - Aerial
- External detachable
- Aerial - Antenna Qty
- 2
- Basic Specifications - Capacity
- Priority QoS queues: 4 ¦ Concurrent VPN tunnels: 2 ¦ NAT sessions: 50000 ¦ DHCP pool: 253 ¦ SSIDs per radio: 4 ¦ VLANs supported: 8
- Basic Specifications - Compliant Standards
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, X.509, IEEE 802.11n, UPnP, ITU-T G.993.1, ITU-T G.993.2, ITU-T G.997.1, IEEE 802.11ac Wave 2
- Basic Specifications - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, PPP, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2
- Basic Specifications - Device Type
- Wireless router - DSL modem - 4-port switch (integrated)
- Basic Specifications - Digital Signaling Protocol
- H.323, ADSL, SIP, ADSL2, ADSL2+, VDSL2
- Basic Specifications - Dimensions (WxDxH)
- 20.7 cm x 13.1 cm x 4.2 cm
- Basic Specifications - EAN
- 4710484745347
- Basic Specifications - Enclosure Type
- Desktop, wall-mountable
- Basic Specifications - Features
- IGMP snooping, DoS attack prevention, content filtering, port mirroring, E-mail alert, LAN-to-LAN bridging, WMM support, file sharing, TFTP support, ACL support, QoS, DPD, IPSec NAT-T, SMS alert, reset button, DNS server, port triggering, 3G/4G USB Dongle Support, TxBF ready, dual-stream (2x2), IGMP proxy, 802.1x authentication, ToS, automated backup scheduling, MU-MIMO technology, fast leave, Inter-VLAN Routing, L2TP over IPSec, black list, white list, DSCP based ToS, wireless access control, DNSSEC support, PPP, IPTV support, EAPOL, OpenVPN pass-through, Brute Force Protection, SIP ALG, DrayDDNS, WAN Budget, Wi-Fi on/off button, DSL mode, USB backup, ping detect, ARP detect, dynamic DNS, Full Feature-set Hardware Acceleration, 2-Level Administration Privilege, Teleworker-to-LAN bridging, ISP Video support, NAT port redirection, DMZ host, spoofing defence, user-based Time Quota, IP-based Firewall Policy
- Basic Specifications - Frequency Band
- 2.4 GHz / 5 GHz
- Basic Specifications - Localisation
- United Kingdom, Ireland
- Basic Specifications - Manufacturer Warranty
- 2-year warranty
- Basic Specifications - Manufacturer's Part Number
- V2763AC-K
- Basic Specifications - Model
- Draytek Vigor 2763ac
- Basic Specifications - Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, PPPoA, AAL5, FTP, DHCP, Bonjour, DHCPv6, RTSP, IPv4, IPv6
- Basic Specifications - Performance
- VPN throughput (256-bit AES IPSec): 200 Mbps ¦ VPN throughput (SSL): 80 Mbps ¦ NAT throughput: 700 Mbps ¦ NAT throughput (with VDSL2): 100 Mbps ¦ NAT throughput with hardware acceleration: 950 Mbps ¦ NAT throughput without hardware acceleration: 700 Mbps ¦ Maximum data rate (2.4 GHz): 400 Mbps ¦ Maximum data rate (5 GHz): 866 Mbps
- Basic Specifications - Power
- AC 100-240 V / DC 12 V
- Basic Specifications - Product Description
- Draytek Vigor 2763ac - wireless router - DSL modem - Wi-Fi 5 - desktop, wall-mountable
- Basic Specifications - Remote Management Protocol
- SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, TR-069, Syslog
- Basic Specifications - Routing Protocol
- MPOA, static IPv4 routing, static IPv6 routing
- Basic Specifications - VoIP Protocols
- H.323, SIP
- Basic Specifications - WAN Ports Qty
- 2
- Basic Specifications - Weight
- 450 g
- Communications - Digital Signaling Protocol
- H.323, ADSL, SIP, ADSL2, ADSL2+, VDSL2
- Communications - Max Transfer Rate
- 300 Mbps
- Communications - Protocols & Specifications
- ITU G.992.1 (G.DMT), ITU G.992.2 (G.Lite), ITU G.992.5 Annex M, ITU G.992.3 Annex M, ITU G.992.5 Annex J, ITU G.992.3 Annex J
- Communications - Type
- DSL modem
- Dimensions & Weight - Depth
- 13.1 cm
- Dimensions & Weight - Height
- 4.2 cm
- Dimensions & Weight - Weight
- 450 g
- Dimensions & Weight - Width
- 20.7 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 90% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 40 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Interfaces
- LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 1 x VDSL2 / ADSL2+ - RJ-11 ¦ USB 2.0: 2 x 4 pin USB Type A ¦ Antenna: 2 x
- General - Authentication Method
- RADIUS, internal user database, Mobile One Time Password (mOTP)
- General - Built-in Devices
- Led panel
- General - Capacity
- Priority QoS queues: 4 ¦ Concurrent VPN tunnels: 2 ¦ NAT sessions: 50000 ¦ DHCP pool: 253 ¦ SSIDs per radio: 4 ¦ VLANs supported: 8
- General - Compliant Standards
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, X.509, IEEE 802.11n, UPnP, ITU-T G.993.1, ITU-T G.993.2, ITU-T G.997.1, IEEE 802.11ac Wave 2, TOTP
- General - Connectivity Technology
- Wireless, wired
- General - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, PPP, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2
- General - Device Type
- Wireless router - 4-port switch (integrated)
- General - Enclosure Type
- Desktop, wall-mountable
- General - Encryption Algorithm
- DES, Triple DES, MPPE, SHA-1, WPA, WPA2, 128-bit AES, 192-bit AES, 256-bit AES, IKEv2, WEP, WPS, WPA3, IKEv1, SHA-256
- General - Features
- IGMP snooping, DoS attack prevention, content filtering, port mirroring, E-mail alert, LAN-to-LAN bridging, WMM support, file sharing, TFTP support, ACL support, QoS, DPD, IPSec NAT-T, SMS alert, reset button, DNS server, port triggering, 3G/4G USB Dongle Support, TxBF ready, dual-stream (2x2), IGMP proxy, 802.1x authentication, ToS, automated backup scheduling, MU-MIMO technology, fast leave, Inter-VLAN Routing, L2TP over IPSec, black list, white list, DSCP based ToS, wireless access control, DNSSEC support, PPP, IPTV support, EAPOL, OpenVPN pass-through, Brute Force Protection, SIP ALG, DrayDDNS, WAN Budget, Wi-Fi on/off button, DSL mode, USB backup, ping detect, ARP detect, dynamic DNS, Full Feature-set Hardware Acceleration, 2-Level Administration Privilege, Teleworker-to-LAN bridging, ISP Video support, NAT port redirection, DMZ host, spoofing defence, user-based Time Quota, IP-based Firewall Policy
- General - Frequency Band
- 2.4 GHz / 5 GHz
- General - Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, PPPoA, AAL5, FTP, DHCP, Bonjour, DHCPv6, RTSP, IPv4, IPv6
- General - Performance
- VPN throughput (256-bit AES IPSec): 200 Mbps ¦ VPN throughput (SSL): 80 Mbps ¦ NAT throughput: 700 Mbps ¦ NAT throughput (with VDSL2): 100 Mbps ¦ NAT throughput with hardware acceleration: 950 Mbps ¦ NAT throughput without hardware acceleration: 700 Mbps ¦ Maximum data rate (2.4 GHz): 400 Mbps ¦ Maximum data rate (5 GHz): 866 Mbps
- General - Remote Management Protocol
- SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, TR-069, Syslog
- General - Routing Protocol
- MPOA, static IPv4 routing, static IPv6 routing
- General - Status Indicators
- WAN, LAN, USB, 5 GHz, 2.4 GHz, QoS
- General - Wi-Fi Rating
- AC1300
- IP Telephony - VoIP Protocols
- H.323, SIP
- Line Properties - Framing Format
- ANSI T1.413i2
- Manufacturer Warranty - Service & Support
- Limited warranty - 2 years
- Miscellaneous - Cables Included
- 1 x network cable - 2 m
- Miscellaneous - Included Accessories
- 2 x WiFi aerials
- Miscellaneous - Localisation
- United Kingdom, Ireland
- Miscellaneous - Mounting Kit
- Included
- Power - Power Consumption Operational
- 21 Watt
- Power - Power Device
- External power adapter
- Power - Voltage Required
- AC 100-240 V / DC 12 V
- Software / System Requirements - OS Provided
- No operating system
