- Aerial - Aerial
- External detachable
- Aerial - Antenna Qty
- 6
- Basic Specifications - Capacity
- Concurrent VPN tunnels: 50 ¦ Concurrent SSL VPN tunnels: 25 ¦ NAT sessions: 60000 ¦ Hardware accelerated NAT sessions: 8000 ¦ SSIDs per radio: 4
- Basic Specifications - Cellular Band
- 5G n1, 5G n3, 5G n7, 5G n8, 5G n20, 5G n28, 5G n38, 5G n40, 5G n77, 5G n78, LTE B3, LTE B7, LTE B8, LTE B20, LTE B28, LTE B38, LTE B40, WCDMA B1, WCDMA B8
- Basic Specifications - Compliant Standards
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, X.509
- Basic Specifications - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), 5G, LTE
- Basic Specifications - Device Type
- Wireless router - wireless cellular modem - 6-port switch (integrated)
- Basic Specifications - Dimensions (WxDxH)
- 24.1 cm x 16.5 cm x 4.4 cm
- Basic Specifications - EAN
- 4712909127387
- Basic Specifications - Enclosure Type
- Desktop, wall-mountable
- Basic Specifications - Features
- On/off switches, firewall protection, NAT support, VPN support, load balancing, IGMP snooping, Syslog support, SPI, DoS attack prevention, content filtering, ALG support, port mirroring, E-mail alert, MAC address filtering, VPN passthrough, firmware upgradable, DDos attack prevention, wall mountable, LAN-to-LAN bridging, tunnelling, WMM support, file sharing, QoS, dual WAN connection, DPD, IPSec NAT-T, WPS, WAN failover, DHCP server, reset button, port triggering, 3G/4G USB Dongle Support, anti-spoofing protection, IP-MAC binding, DHCP client, IGMP proxy, ToS, MU-MIMO technology, beamforming technology, band steering, failover protection, IGMP fast leave, Airtime Fairness, DMZ support, VLAN Tagging, port-based VLAN, DNSSEC support, DHCP over IPSec, PPP, DSCP based QoS, Brute Force Protection
- Basic Specifications - Frequency Band
- 2.4 GHz / 5 GHz
- Basic Specifications - Localisation
- United Kingdom, Ireland
- Basic Specifications - Manufacturer Warranty
- 2-year warranty
- Basic Specifications - Manufacturer's Part Number
- V2927LAX-5G-K
- Basic Specifications - Mobile Communication Protocol
- 5G NR, LTE, WCDMA
- Basic Specifications - Model
- Draytek Vigor 2927Lax 5G
- Basic Specifications - Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, ARP, FTP, DHCP, DNS, Bonjour, SMB, DDNS, DHCPv6, RTSP, IPv4, IPv6
- Basic Specifications - Performance
- NAT throughput for single WAN with hardware acceleration: 950 Mbps ¦ NAT throughput for dual WAN with hardware acceleration: 1.8 Gbps ¦ NAT throughput: 800 Mbps ¦ VPN throughput (256-bit AES IPSec): 300 Mbps ¦ VPN throughput (IPSec): 800 Mbps ¦ VPN throughput (SSL): 120 Mbps ¦ Maximum data rate (5 GHz): 2400 Mbps ¦ Maximum data rate (2.4 GHz): 574 Mbps
- Basic Specifications - Power
- AC 100-240 V
- Basic Specifications - Product Description
- Draytek Vigor 2927Lax 5G - wireless router - WWAN - Wi-Fi 6 - desktop, wall-mountable
- Basic Specifications - Remote Management Protocol
- SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, TR-069
- Basic Specifications - Routing Protocol
- RIP-1, RIP-2, BGP, GRE, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), RIPng
- Basic Specifications - WAN Ports Qty
- 2
- Basic Specifications - Weight
- 670 g
- Communications - Cellular Band
- 5G n1, 5G n3, 5G n7, 5G n8, 5G n20, 5G n28, 5G n38, 5G n40, 5G n77, 5G n78, LTE B3, LTE B7, LTE B8, LTE B20, LTE B28, LTE B38, LTE B40, WCDMA B1, WCDMA B8
- Communications - Max Transfer Rate
- 2.4 Gbps
- Communications - Mobile Communication Protocol
- 5G NR, LTE, WCDMA
- Communications - Type
- Wireless cellular modem
- Dimensions & Weight - Depth
- 16.5 cm
- Dimensions & Weight - Height
- 4.4 cm
- Dimensions & Weight - Weight
- 670 g
- Dimensions & Weight - Width
- 24.1 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 90% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 45 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Expansion Slots
- 2 (total) / 2 (free) x SIM
- Expansion / Connectivity - Interfaces
- LAN: 5 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB: 1 x 4 pin USB Type A ¦ Antenna: 4 x SMA - 5G ¦ Antenna: 2 x RP-SMA - Wi-Fi
- General - Authentication Method
- RADIUS, X.509 certificates, TACACS+, LDAP, XAUTH authentication
- General - Built-in Devices
- Led panel
- General - Capacity
- Concurrent VPN tunnels: 50 ¦ Concurrent SSL VPN tunnels: 25 ¦ NAT sessions: 60000 ¦ Hardware accelerated NAT sessions: 8000 ¦ SSIDs per radio: 4
- General - Compliant Standards
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, X.509, RoHS, UKCA
- General - Connectivity Technology
- Wireless, wired
- General - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), 5G, LTE
- General - Device Type
- Wireless router - 6-port switch (integrated)
- General - Enclosure Type
- Desktop, wall-mountable
- General - Encryption Algorithm
- DES, Triple DES, MPPE, IKE, SSL, SHA-1, WPA2, 128-bit AES, 192-bit AES, 256-bit AES, IKEv2, WEP, WPA3, SHA-256
- General - Features
- On/off switches, firewall protection, NAT support, VPN support, load balancing, IGMP snooping, Syslog support, SPI, DoS attack prevention, content filtering, ALG support, port mirroring, E-mail alert, MAC address filtering, VPN passthrough, firmware upgradable, DDos attack prevention, wall mountable, LAN-to-LAN bridging, tunnelling, WMM support, file sharing, QoS, dual WAN connection, DPD, IPSec NAT-T, WPS, WAN failover, DHCP server, reset button, port triggering, 3G/4G USB Dongle Support, anti-spoofing protection, IP-MAC binding, DHCP client, IGMP proxy, ToS, MU-MIMO technology, beamforming technology, band steering, failover protection, IGMP fast leave, Airtime Fairness, DMZ support, VLAN Tagging, port-based VLAN, DNSSEC support, DHCP over IPSec, PPP, DSCP based QoS, Brute Force Protection
- General - Frequency Band
- 2.4 GHz / 5 GHz
- General - Network / Transport Protocol
- PPTP, L2TP, IPSec, PPPoE, ARP, FTP, DHCP, DNS, Bonjour, SMB, DDNS, DHCPv6, RTSP, IPv4, IPv6
- General - Performance
- NAT throughput for single WAN with hardware acceleration: 950 Mbps ¦ NAT throughput for dual WAN with hardware acceleration: 1.8 Gbps ¦ NAT throughput: 800 Mbps ¦ VPN throughput (256-bit AES IPSec): 300 Mbps ¦ VPN throughput (IPSec): 800 Mbps ¦ VPN throughput (SSL): 120 Mbps ¦ Maximum data rate (5 GHz): 2400 Mbps ¦ Maximum data rate (2.4 GHz): 574 Mbps
- General - Remote Management Protocol
- SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, TR-069
- General - Routing Protocol
- RIP-1, RIP-2, BGP, GRE, static IPv4 routing, static IPv6 routing, policy-based routing (PBR), RIPng
- General - Status Indicators
- WAN, DMZ, link/activity, USB, 5 GHz, 2.4 GHz, QoS
- General - Wi-Fi Rating
- AX3000
- Manufacturer Warranty - Service & Support
- Limited warranty - 2 years
- Miscellaneous - Cables Included
- 1 x network cable - 2 m ¦ 4 x aerial extension cable - 1 m
- Miscellaneous - Included Accessories
- 2 x WiFi aerials, 4 x LTE/5G aerials
- Miscellaneous - Localisation
- United Kingdom, Ireland
- Power - Power Consumption Operational
- 31.2 Watt
- Power - Power Device
- External power adapter
- Power - Voltage Required
- AC 100-240 V
