- Basic Specifications - Device Type
- UPS - rack-mountable / external
- Basic Specifications - Dimensions (WxDxH)
- 43.8 cm x 44.8 cm x 8.55 cm
- Basic Specifications - EAN
- 3553340620843
- Basic Specifications - Environmental Standards
- ENERGY STAR
- Basic Specifications - Included Accessories
- Tower stand
- Basic Specifications - Input Connectors
- 1 x power IEC 60320 C14
- Basic Specifications - Manufacturer Warranty
- 3-year warranty
- Basic Specifications - Manufacturer's Part Number
- 5PX1000IRT2UG2BS
- Basic Specifications - Model
- Eaton 5PX G2
- Basic Specifications - Networking
- RS-232, USB
- Basic Specifications - Output connectors
- 8 x power IEC 60320 C13
- Basic Specifications - Output Voltage
- AC 200/208/220/230/240 V + 6% / - 10%
- Basic Specifications - Power Capacity
- 1000 Watt / 1000 VA
- Basic Specifications - Product Description
- Eaton 5PX G2 - UPS - 1000 Watt - 1000 VA
- Basic Specifications - Product Type
- UPS
- Basic Specifications - Rack Size
- 19" - 2U
- Basic Specifications - Run Time (Up To)
- 8 min at 80% load
- Basic Specifications - Weight
- 19.6 kg
- Battery - Run Time (Up To)
- 30 min at 300 Watts ¦ 17 min at 500 Watts ¦ 8 min at 800 Watts
- Dimensions & Weight - Depth
- 44.8 cm
- Dimensions & Weight - Height
- 8.55 cm
- Dimensions & Weight - Weight
- 19.6 kg
- Dimensions & Weight - Width
- 43.8 cm
- Environmental Parameters - Humidity Range Operating
- 0 - 90% RH (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 40 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Environmental Parameters - Sound Emission
- 40 dBA
- Environmental Standards - ENERGY STAR
- Yes
- Expansion / Connectivity - Expansion Slots
- 1 (total) / 1 (free) x Expansion Slot
- Expansion / Connectivity - Interfaces
- 1 x management (RS-232) - 9 pin D-Sub (DB-9) ¦ 1 x management (USB) - 4 pin USB Type B ¦ Remote power (on/off) - mini terminal block ¦ Relay output - mini terminal block
- General - Device Type
- UPS - rack-mountable / external
- General - Height (Rack Units)
- 2U
- General - Rack Size
- 19"
- Manufacturer Warranty - Service & Support
- Limited warranty - 3 years ¦ Limited warranty - batteries - 2 years
- Miscellaneous - Cables Included
- 2 x power cable - external ¦ Serial cable - external ¦ USB cable - external
- Miscellaneous - Compliant Standards
- CM, CSA 22.2, cTUVus, EAC, EN 62040-1, EN 62040-2, EN 62040-3, IEC 62040-1, IEC 62040-2, IEC 62040-3, REACH, RoHS, UKCA, UL 1778
- Miscellaneous - Features
- Advance Battery Management (ABM), deep discharge protection, LCD display, temperature-compensated battery charging, hot-swappable batteries
- Miscellaneous - Included Accessories
- Tower stand
- Miscellaneous - Rack Mounting Kit
- Included
- Networking - Remote Management Interface
- RS-232, USB
- Power Device - Frequency Provided
- 50/60 Hz ± 0.1Hz
- Power Device - Frequency Required
- 47 - 70 Hz
- Power Device - Input Connectors
- 1 x power IEC 60320 C14
- Power Device - Input Voltage Range
- AC 160 - 294 V
- Power Device - Input Voltage Range (Adjustable)
- AC 150 - 294 V
- Power Device - Max Electric Current
- 10 A
- Power Device - Output Voltage
- AC 200/208/220/230/240 V + 6% / - 10% - 50/60 Hz
- Power Device - Output Waveform
- Sinewave
- Power Device - Power Capacity
- 1000 Watt / 1000 VA
- Power Device - Power Output Connectors Details
- 8 x power IEC 60320 C13
- Power Device - UPS Technology
- Line interactive
- Sustainability Information - ENERGY STAR
- Yes
