- Basic Specifications - Capacity
- MSTP instances: 8 ¦ RPVST+ instances: 126 ¦ Link aggregation groups: 8 ¦ Link aggregation ports: 8 ¦ VLAN IDs: 4093 ¦ IGMP multicast groups: 2000 ¦ IPv4 routes (static): up to 990 ¦ IPv4 interfaces: 128 ¦ ACL rules: 1024 ¦ Priority queues: 8 ¦ Packet buffer size: 1.5 MB
- Basic Specifications - Compliant Standards
- IEEE 802.1x, IEEE 802.3az, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at
- Basic Specifications - Device Type
- Switch - 24 ports - L3 - Managed - stackable
- Basic Specifications - Dimensions (WxDxH)
- 44.5 cm x 34.5 cm x 4.4 cm
- Basic Specifications - EAN
- 0889728521505
- Basic Specifications - Enclosure Type
- Rack-mountable
- Basic Specifications - Features
- 1 fan, VLAN support, STP support, CLI management, ATP, FHS, QoS, sFlow, dynamic routing, Zero-Touch Deployment, Port Security, Web authentication, Address Resolution Protocol, ARP inspection, IP source guard, DHCP snooping, IPMB, NDP, router advertisement guard, DHCPv6 guard, layer 3 routing, LAG, port mirroring, eco-friendly button, EEE, RSTP, MSTP support, PVST+, RPVST+, LACP, Protocol-based VLANs support, MAC based VLAN, VLAN management, Private VLAN, PVE, Guest VLAN, GVRP, CPE VLAN, Auto Surveillance VLAN, MVR, Q-in-Q tunnelling, TPID, GARP, UDLD, DHCP relay, DHCP server, IGMP snooping, IGMP querier, IGMP proxy, HoL Blocking Prevention, loopback detection, ACL support, BOOTP support, UDP, High Availability, MAC address authentication, BPDU Guard, STP Root Guard, STP loop guard, DAI, DoS protection, SCT, SSD, trustworthy systems, Broadcast Storm Control, Multicast Storm Control, Storm Control, Unicast Storm Control, Unknown Storm Control, DoS attack prevention, WRR, ToS, DSCP based CoS, DiffServ support, TCP congestion, iSCSI traffic optimisation, path MTU discovery, DAD, RA guard, MLD snooping, MLD proxy, Telnet server, DNS client, Telnet client, DHCP client, Cisco NG PnP Protocol, IPv4 and IPv6 dual stack, VLAN mirroring, RSPAN, SCP, chip guard, boot integrity, persistent PoE, PoE scheduling, time-based port operation, cable length detection, LLDP, LLDP-MED, reset button
- Basic Specifications - Jumbo Frame Support
- 9000 bytes
- Basic Specifications - MAC Address Table Size
- 16000 entries
- Basic Specifications - Manufacturer Warranty
- Limited lifetime warranty
- Basic Specifications - Manufacturer's Part Number
- C1300-24FP-4X
- Basic Specifications - Model
- Cisco Catalyst 1300-24FP-4X
- Basic Specifications - Performance
- Forwarding rate (64-byte packets): 95.23 Mpps ¦ Switching capacity: 128 Gbps
- Basic Specifications - PoE Budget
- 375 W
- Basic Specifications - Ports
- 24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
- Basic Specifications - Power
- AC 100-240 V (50 - 60 Hz)
- Basic Specifications - Power Over Ethernet (PoE)
- PoE+
- Basic Specifications - Product Description
- Cisco Catalyst 1300-24FP-4X - switch - 24 ports - Managed - rack-mountable
- Basic Specifications - Remote Management Protocol
- CLI, SNMP, Telnet, SSH, SSH-2, DHCP, SCP, HTTPS, HTTP, ICMP, TFTP, Syslog, SNMP 2c, SNMP 3, RMON, RADIUS
- Basic Specifications - Routing Protocol
- STP, static IP routing, RSTP, MSTP, IGMP, IGMPv2, IGMPv3, CIDR, RIP-2, policy-based routing (PBR), MLD, MLDv2, Bounjour
- Basic Specifications - Subtype
- Gigabit Ethernet
- Basic Specifications - Weight
- 4.6 kg
- Dimensions & Weight - Depth
- 34.5 cm
- Dimensions & Weight - Height
- 4.4 cm
- Dimensions & Weight - Weight
- 4.6 kg
- Dimensions & Weight - Width
- 44.5 cm
- Environmental Parameters - Humidity Range Operating
- 5 - 90% RH (non-condensing)
- Environmental Parameters - Humidity Range Storage
- 5 - 90% RH (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 50 °C
- Environmental Parameters - Max Storage Temperature
- 70 °C
- Environmental Parameters - Min Operating Temperature
- -5 °C
- Environmental Parameters - Min Storage Temperature
- -25 °C
- Expansion / Connectivity - Interfaces
- 24 x 10/100/1000 Base-T (PoE+) RJ-45 ¦ 4 x 10GBase-X SFP+ ¦ 1 x console RJ-45 ¦ 1 x USB-C console
- General - Authentication Method
- RADIUS, TACACS+
- General - Capacity
- MSTP instances: 8 ¦ RPVST+ instances: 126 ¦ Link aggregation groups: 8 ¦ Link aggregation ports: 8 ¦ VLAN IDs: 4093 ¦ IGMP multicast groups: 2000 ¦ IPv4 routes (static): up to 990 ¦ IPv4 interfaces: 128 ¦ ACL rules: 1024 ¦ Priority queues: 8 ¦ Packet buffer size: 1.5 MB
- General - Compliant Standards
- IEEE 802.1x, IEEE 802.3az, IEEE 802.1D, IEEE 802.1w, IEEE 802.1s, IEEE 802.3ad (LACP), IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at
- General - Device Type
- Switch - 24 ports - L3 - Managed - stackable
- General - Enclosure Type
- Rack-mountable
- General - Encryption Algorithm
- SSL, MD5
- General - Features
- 1 fan, VLAN support, STP support, CLI management, ATP, FHS, QoS, sFlow, dynamic routing, Zero-Touch Deployment, Port Security, Web authentication, Address Resolution Protocol, ARP inspection, IP source guard, DHCP snooping, IPMB, NDP, router advertisement guard, DHCPv6 guard, layer 3 routing, LAG, port mirroring, eco-friendly button, EEE, RSTP, MSTP support, PVST+, RPVST+, LACP, Protocol-based VLANs support, MAC based VLAN, VLAN management, Private VLAN, PVE, Guest VLAN, GVRP, CPE VLAN, Auto Surveillance VLAN, MVR, Q-in-Q tunnelling, TPID, GARP, UDLD, DHCP relay, DHCP server, IGMP snooping, IGMP querier, IGMP proxy, HoL Blocking Prevention, loopback detection, ACL support, BOOTP support, UDP, High Availability, MAC address authentication, BPDU Guard, STP Root Guard, STP loop guard, DAI, DoS protection, SCT, SSD, trustworthy systems, Broadcast Storm Control, Multicast Storm Control, Storm Control, Unicast Storm Control, Unknown Storm Control, DoS attack prevention, WRR, ToS, DSCP based CoS, DiffServ support, TCP congestion, iSCSI traffic optimisation, path MTU discovery, DAD, RA guard, MLD snooping, MLD proxy, Telnet server, DNS client, Telnet client, DHCP client, Cisco NG PnP Protocol, IPv4 and IPv6 dual stack, VLAN mirroring, RSPAN, SCP, chip guard, boot integrity, persistent PoE, PoE scheduling, time-based port operation, cable length detection, LLDP, LLDP-MED, reset button
- General - Flash Memory
- 512 MB
- General - Jumbo Frame Support
- 9000 bytes
- General - MAC Address Table Size
- 16000 entries
- General - Max Units In A Stack
- 8
- General - Performance
- Forwarding rate (64-byte packets): 95.23 Mpps ¦ Switching capacity: 128 Gbps
- General - PoE Budget
- 375 W
- General - Ports
- 24 x 10/100/1000 (PoE+) + 4 x 10 Gigabit SFP+
- General - Power Over Ethernet (PoE)
- PoE+
- General - Processor
- X ARM: 1.4 GHz
- General - RAM
- 1 GB DDR4 SDRAM
- General - Remote Management Protocol
- CLI, SNMP, Telnet, SSH, SSH-2, DHCP, SCP, HTTPS, HTTP, ICMP, TFTP, Syslog, SNMP 2c, SNMP 3, RMON, RADIUS
- General - Routing Protocol
- STP, static IP routing, RSTP, MSTP, IGMP, IGMPv2, IGMPv3, CIDR, RIP-2, policy-based routing (PBR), MLD, MLDv2, Bounjour
- General - Status Indicators
- System, link/activity/speed, PoE
- General - Subtype
- Gigabit Ethernet
- Manufacturer Warranty - Service & Support
- Limited warranty - lifetime - response time: next business day ¦ Technical support - consulting - 1 year
- Miscellaneous - Compliant Standards
- Plug and Play, RFC768, RFC783, RFC791, RFC792, RFC793, RFC813, RFC826, RFC879, RFC896, RFC854, RFC855, RFC856, RFC858, RFC894, RFC919, RFC920, RFC922, RFC950, RFC951, RFC1042, RFC1071, RFC1123, RFC1141, RFC1155, RFC1157, RFC1213, RFC1215, RFC1286, RFC1350, RFC1442, RFC1451, RFC1493, RFC1533, RFC1541, RFC1542, RFC1573, RFC1624, RFC1643, RFC1700, RFC1757, RFC1867, RFC1907, RFC2011, RFC2012, RFC2013, RFC2030, RFC2131, RFC2132, RFC2233, RFC2576, RFC2616, RFC2618, RFC2665, RFC2666, RFC2674, RFC2737, RFC2819, RFC2863, RFC3164, RFC3176, RFC3411, RFC3412, RFC3413, RFC3414, RFC3415, RFC3416, RFC4330, RFC4443, RFC4291, RFC2460, RFC4861, RFC4862, RFC1981, RFC4007, RFC3484, RFC5214, RFC4293, RFC3595, CSA 22.2, FCC CFR47 Part 15, UL 62368, WEEE
- Miscellaneous - Included Accessories
- Pointer card, mounting kit
- Miscellaneous - MTBF
- 698,220 hours
- Power - Power Device
- Internal power supply
- Power - Voltage Required
- AC 100-240 V (50 - 60 Hz)
