- 1080p Passthrough :
- Up to 240Hz
- 1440p Passthrough :
- Up to 144Hz
- Audio Input :
- 3.5mm TRS Stereo Line-In
- Av connections - Inputs
- HDMI 2.0 x 1- 3.5 mm jack x 1
- Av connections - Outputs
- HDMI 2.0 x 1
- Basic Specifications - EAN
- 840440406815
- Brand :
- Elgato
- Capture Interface :
- USB Type-C
- Capture Software :
- Elgato Studio, OBS Studio, Meld Studio and Other Compatible Applications
- Colour :
- Black
- Computer Compatibility :
- Compatible Windows PCs and Macs
- Connection Type :
- External USB-C
- Features - Compatible streaming websites
- Elgato Studio- OBS (out of the box)
- Features - HDMI pass-through
- Yes
- Features - Maximum resolution
- Passthrough: 4K at 60 fps- Capture & stream: 4K at 60 fps - HDR10 Passthrough: 4K at 60 fps- HDR10 Capture: Full HD at 60 fps
- General - Box contents
- Elgato 4K S Gaming Capture Card- USB Type-C cable- HDMI 2.0 cable
- General - Dimensions
- 17 x 112 x 72 mm (H x W x D)
- General - Weight
- 91 g
- HDCP Support :
- Encrypted HDMI Sources Cannot Be Captured
- HDR Capture :
- Up to 1080p60 on Windows
- HDR Passthrough :
- HDR10, Up to 4K60
- Maximum Capture Frame Rate at 1080p :
- Up to 120fps
- Maximum Capture Resolution :
- 4K (3840 x 2160) at 60fps
- Maximum Passthrough Resolution :
- 4K at 60fps
- Model :
- 4K S
- Nintendo Compatibility :
- Nintendo Switch 2 and Nintendo Switch
- Overview - Compatibility
- PS5- Xbox Series X/S- Switch 2- Xbox- Playstation- PC- Mac- iPad
- Overview - PC interface
- USB Type-C- HDMI
- PlayStation Compatibility :
- PlayStation 5 and PlayStation 4/Pro
- Power Supply :
- USB Bus Power
- Product Dimensions :
- Approximately 112 x 72 x 17mm
- Product Name :
- Game Capture 4K S
- Product Type :
- External Video Capture Card
- Product Weight :
- Approximately 90g
- Requirements - System requirements
- Windows 11 or later- MacOS 13 or later
- Streaming Platforms :
- Compatible Streaming Applications and Services
- Tablet Compatibility :
- Compatible iPads
- USB Data Transfer Rate :
- Up to 5Gbps
- USB Standard :
- USB 3.0
- Variable Refresh Rate :
- Supported
- Video Capture Formats :
- 2160p, 1440p, 1080p, 720p and Supported Lower Resolutions
- Video Encoding :
- Software-Based Encoding Through Compatible Applications
- Video Input :
- HDMI 2.0
- Video Output :
- HDMI 2.0 Passthrough
- Xbox Compatibility :
- Xbox Series X, Xbox Series S and Supported Xbox One Consoles
