- Basic Specifications - Capacity
- 512 GB
- Basic Specifications - Dimensions (WxDxH)
- 22 mm x 80 mm x 2.25 mm
- Basic Specifications - EAN
- 5055288447356
- Basic Specifications - Features
- InnoGrit IG5216, NVM Express (NVMe) 1.4, TRIM support, Wear Leveling Support, Ultra-efficient Block Management, S.M.A.R.T.
- Basic Specifications - Form Factor
- M.2 2280
- Basic Specifications - Interface
- PCIe 3.1 x4 (NVMe)
- Basic Specifications - Manufacturer Warranty
- 3-year warranty
- Basic Specifications - Manufacturer's Part Number
- INSSD512GM280NM2
- Basic Specifications - Model
- Integral M2 Series
- Basic Specifications - NAND Flash Memory Type
- 3D triple-level cell (TLC)
- Basic Specifications - Product Description
- Integral M2 Series - SSD - 512 GB - PCIe 3.1 x4 (NVMe)
- Basic Specifications - Type
- Solid state drive - internal
- Basic Specifications - Weight
- 10 g
- Dimensions & Weight (Shipping) - Shipping Weight
- 58 g
- Environmental Parameters - Humidity Range Operating
- 5 - 95% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 70 °C
- Environmental Parameters - Max Storage Temperature
- 85 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Environmental Parameters - Min Storage Temperature
- -40 °C
- Environmental Parameters - Shock Tolerance (non-operating)
- 1500 g @ 0.5 ms half-sine wave
- Environmental Parameters - Vibration Tolerance (non-operating)
- 20 g @ 10-2000 Hz
- Expansion & Connectivity - Compatible Bay
- M.2 2280
- Expansion & Connectivity - Interfaces
- 1 x PCI Express 3.1 x4 (NVMe) - M.2 Card
- General - Capacity
- 512 GB
- General - Depth
- 80 mm
- General - Device Type
- Solid state drive - internal
- General - Features
- InnoGrit IG5216, NVM Express (NVMe) 1.4, TRIM support, Wear Leveling Support, Ultra-efficient Block Management, S.M.A.R.T.
- General - Form Factor
- M.2 2280
- General - Height
- 2.25 mm
- General - Interface
- PCIe 3.1 x4 (NVMe)
- General - NAND Flash Memory Type
- 3D triple-level cell (TLC)
- General - Weight
- 10 g
- General - Width
- 22 mm
- Manufacturer Warranty - Service & Support
- Limited warranty - 3 years
- Miscellaneous - Compliant Standards
- FCC, RoHS, UKCA
- Performance - 4KB Random Read
- 188000 IOPS
- Performance - 4KB Random Write
- 156000 IOPS
- Performance - Internal Data Rate
- 3450 MBps (read) / 2400 MBps (write)
- Performance - SSD Endurance
- 128 TB
- Power - Power Consumption
- 2822 mW (read) ¦ 1056 mW (idle) ¦ 2970 mW (write)
- Reliability - MTBF
- 1,500,000 hours
