- Basic Specifications - EAN
- 4711387772676
- Basic Specifications - Manufacturer's Part Number
- 126167
- External connectivity - Audio
- Audio jacks x 2
- External connectivity - LAN
- - Intel® 2.5Gb Ethernet x 1- ASUS LANGuard
- External connectivity - Other external connections
- - WiFi module x 1- Optical S/PDIF out port x 1
- External connectivity - USB
- Rear:- USB Type-C (20Gbps) x 1- USB Type-A (10Gbps) x 2- USB Type-C (10Gbps) x 1- USB Type-A (5Gbps) x 4- USB 2.0 x 2Front:- USB Type-C (10Gbps) x 1 connector (supports USB Type-C®)- USB 5Gbps (supports 2 additional USB 5Gbps ports) x 1- USB 2.0 (support 4 additional USB 2.0 ports) x 2
- External connectivity - Video output
- - HDMI x 1- DisplayPort x 1
- General - Box contents
- - Asus ROG STRIX Gaming WiFi B850-A AM5 Motherboard- SATA 6Gb/s cable x 2- ASUS WiFi Q-antenna x 1- Cable ties package x 1- M.2 Q-Latch x 1- M.2 Q-Slide x 1- ROG key chain x 1- ROG Strix sticker x 1- M.2 rubber x 4- Installation Media- USB drive with utilities and drivers x 1- Documentation- Quick start guide
- General - Colour
- Black
- General - Dimensions
- 305 x 244 x 20 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Software included
- ROG Exclusive Software:- ROG CPU-Z- Dolby AtmosASUS Exclusive Software:- Armoury Crate- AIDA64 Extreme (60 days free trial)- Aura Creator- Aura Sync- Fan Xpert 4- GameFirst- HWiNFO- Power Saving- ASUS DriverHub- ASUS GlideX- TurboV Core- UEFI BIOSASUS EZ DIY:- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ Mode- ASUS MyHotkey
- General - Weight
- 1.59 kg
- Internal connectivity - BIOS
- - 256 Mb Flash ROM- UEFI AMI BIOS
- Internal connectivity - Buttons
- - Power- Reset- BIOS FlashBack
- Internal connectivity - Case
- - BIOS FlashBack button x 1- Clear CMOS button x 1
- Internal connectivity - Cooling
- - CPU fan header 4-pin x 1- CPU OPT fan header 4-pin x 1- AIO Pump header 4-pin x 1- Chassis fan headers 4-pin x 4
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16) (supports x16 mode) x 1- PCIe 4.0 (x16) (support x4 mode) x 1
- Internal connectivity - Other internal connections
- - Thunderbolt 4 header x 1- Addressable Gen 2 headers x 3- CPU Over voltage jumper x 1- Front Panel Audio header x 1- 10-1 pin Front System Panel header x 1- Power button x 1
- Internal connectivity - Power
- - 24-pin main power connector x 1- 8-pin +12V CPU Power connector x 2
- Internal connectivity - Sensors
- Thermal sensor header x 1
- Internal connectivity - Storage slots
- - SATA x 2 (6 GB/s)- M.2 x 4
- Internal connectivity - USB
- - USB Type-C (10Gbps) x 1 connector - USB 5Gbps (supports 2 additional USB 5Gbps ports) x 1- USB 2.0 (support 4 additional USB 2.0 ports) x 2
- Overview - Chipset
- AMD B850
- Overview - Form factor
- ATX
- Overview - Memory slots
- 4 x DIMM (Max RAM: 192 GB)
- Overview - Memory standard
- DDR5
- Overview - Multi-GPU support
- No
- Overview - Operating systems supported
- Windows 11
- Overview - Processor models supported
- AMD Ryzen 9000, 8000 & 7000 Series desktop processors
- Overview - Socket
- AMD AM5
