- Basic Specifications - EAN
- 4711387732045
- Basic Specifications - Manufacturer's Part Number
- 125653
- External connectivity - Audio
- Audio jacks x 2
- External connectivity - LAN
- - Intel® 2.5Gb Ethernet x 1- ASUS LANGuard
- External connectivity - Other external connections
- - DisplayPort x 1 - HDMI port x 1- Wi-Fi module x 1- Intel® 2.5Gb Ethernet x 1- Audio jacks x 1- Optical S/PDIF out port x 1- BIOS FlashBack™ button x 1- Clear CMOS button x 1
- External connectivity - USB
- - USB Type-C x 4- USB 3.0 x 11- USB 2.0 x 6
- External connectivity - Video output
- - HDMI x 1- DisplayPort x 1
- General - Box contents
- - Asus ROG STRIX X870-F WiFi AMD AM5 Motherboard- Cables- SATA 6Gb/s cables x 2- Additional Cooling Kit- Thermal pad for M.2 22110 x 1- ASUS WiFi Q-Antenna x 1- Cable ties package x 1 - M.2 Q-Latch package x 1 - M.2 Q-Slide package x 1- ROG key chain x 1- ROG Strix stickers x 1- M.2 rubber packages x 4- Documentation- Quick start guide
- General - Colour
- Black
- General - Dimensions
- 25 x 244 x 305 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Software included
- - ROG CPU-Z- Dolby Atmos-ASUS Exclusive Software-Armoury Crate- AIDA64 Extreme (60 days free trial) - Aura Creator- Aura Sync- Fan Xpert 4 (with AI Cooling II)- GameFirst- HWiNFO- Power Saving- ASUS Driver Hub- ASUS GlideX- USB Wattage Watcher- TurboV Core - Adobe Creative Cloud (Free Trial)- Norton 360 for Gamers (60 Days Free Trial)- WinRAR (40 Days Free Trial)- UEFI BIOS- AI Overclocking Guide- ASUS EZ DIY - ASUS CrashFree BIOS 3 - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode- ASUS MyHotkey- Dynamic OC Switcher- FlexKey
- General - Weight
- 1.90 kg
- Internal connectivity - BIOS
- - 256 Mb Flash ROM- UEFI AMI BIOS
- Internal connectivity - Buttons
- - Power- Reset- BIOS FlashBack
- Internal connectivity - Case
- - Power LED x 1- Clear CMOS header x 1
- Internal connectivity - Cooling
- - 4-pin CPU fan header x 1- 4-pin CPU OPT fan header x 1- 4-pin AIO Pump header x 1- 4-pin chassis fan headers x 5
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16 slots) x 1- PCIe 4.0 (x16 slots) x 2
- Internal connectivity - Other internal connections
- - Addressable Gen 2 headers x 3- Alteration PCIe mode switch x 1- Chassis Intrusion header x 1- CPU Over voltage jumper x 1- Front Panel Audio header (F_AUDIO) x 1- Start button x 1- 10-1 pin System Panel header x 1- Thermal Sensor header x 1
- Internal connectivity - Power
- - 24-pin EATX x 1- 8-pin ATX 12 V x 1
- Internal connectivity - Sensors
- Thermal sensor header
- Internal connectivity - Storage slots
- - SATA x 2 (6 GB/s)- M.2 x 4
- Overview - Chipset
- AMD X870
- Overview - Form factor
- ATX
- Overview - Memory slots
- DIMM (Max RAM: 192 GB) x 4
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- Windows 11
- Overview - Processor models supported
- AMD RYZEN 7000 / 8000 / 9000 processors
- Overview - Socket
- AMD AM5
