- Aerial - Antenna
- Internal
- Aerial - Directivity
- Omni-directional
- Basic Specifications - Data Link Protocol
- Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- Basic Specifications - Device Type
- Radio access point
- Basic Specifications - Dimensions (WxDxH)
- 16 cm x 16 cm x 3.7 cm
- Basic Specifications - EAN
- 0190017445397
- Basic Specifications - Form Factor
- Wall / ceiling mountable - indoor
- Basic Specifications - Frequency Band
- 2.4 GHz, 5 GHz
- Basic Specifications - Included Accessories
- Wall/ceiling rail mounting clip
- Basic Specifications - Manufacturer Warranty
- 1-year warranty
- Basic Specifications - Manufacturer's Part Number
- R4W02A
- Basic Specifications - Model
- HPE Networking Instant On AP22 (RW)
- Basic Specifications - Performance
- Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps
- Basic Specifications - Power Over Ethernet (PoE) Supported
- PoE
- Basic Specifications - Product Description
- HPE Networking Instant On AP22 (RW) - radio access point - Bluetooth, Wi-Fi 6
- Basic Specifications - Weight
- 500 g
- Environmental Parameters - Max Operating Temperature
- 40 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Interfaces
- 1 x Ethernet 1000 (uplink)
- General - Depth
- 16 cm
- General - Device Type
- Radio access point
- General - Height
- 3.7 cm
- General - Ruggedized Design
- Indoor
- General - Weight
- 500 g
- General - Width
- 16 cm
- Internet of Things (IoT) - Communications Technology
- Bluetooth Low Energy (LE)
- Internet of Things (IoT) - Internet of Things (IoT) Compatible
- Yes
- Manufacturer Warranty - Service & Support
- Limited warranty - 1 year ¦ Technical support - phone consulting - 90 days ¦ Product info support - web support - 1 year
- Miscellaneous - Cables Included
- 1 x network cable
- Miscellaneous - Compliant Standards
- UL 2043, EN 60601-1-2, EN 60601-1-1
- Miscellaneous - Included Accessories
- Wall/ceiling rail mounting clip
- Miscellaneous - MTBF
- 91 years
- Networking - Compliant Standards
- IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6
- Networking - Connectivity Technology
- Wireless
- Networking - Data Link Protocol
- Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
- Networking - Encryption Algorithm
- WPA2, WPA3
- Networking - Features
- Firewall protection, manageable, static IP mode, Trusted Platform Module (TPM), reset button, Low Density Parity Check (LDPC), Transmit Beam-forming (TxBF) ready, security lock slot (cable lock sold separately), Advanced Cellular Coexistence (ACC), MU-MIMO technology, 2x2 MIMO technology, Bluetooth (BLE) clients support, Target Wait Time (TWT), Smart Mesh technology, BSS Coloring
- Networking - Form Factor
- Wall / ceiling mountable
- Networking - Frequency Band
- 2.4 GHz, 5 GHz
- Networking - Line Coding Format
- 1024 QAM
- Networking - Network / Transport Protocol
- PPPoE
- Networking - Performance
- Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (2.4 GHz): 574 Mbps
- Networking - Spread Spectrum Method
- OFDMA
- Networking - Status Indicators
- Status
- Power - Power Over Ethernet (PoE) Supported
- PoE
- Software / System Requirements - Software Included
- InstantOn
