- Aerial - Antenna
- Internal
- Aerial - Gain Level
- 6 dBi
- Basic Specifications - Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth 5.0 LE, IEEE 802.11ax (Wi-Fi 6)
- Basic Specifications - Device Type
- Radio access point
- Basic Specifications - Dimensions (WxDxH)
- 20.2 cm x 12.4 cm x 2.58 cm
- Basic Specifications - EAN
- 0810979019046
- Basic Specifications - Form Factor
- External
- Basic Specifications - Frequency Band
- 2.4 GHz, 5 GHz
- Basic Specifications - Manufacturer Warranty
- Limited lifetime warranty
- Basic Specifications - Manufacturer's Part Number
- MR28-HW
- Basic Specifications - Model
- Cisco Meraki MR28
- Basic Specifications - Performance
- Maximum data rate (5 GHz): 1201 Mbps ¦ Maximum data rate (2.4 GHz): 286 Mbps
- Basic Specifications - Power Over Ethernet (PoE) Supported
- PoE
- Basic Specifications - Product Description
- Cisco Meraki MR28 - radio access point - entry level - Wi-Fi 6, Bluetooth - cloud-managed
- Basic Specifications - Weight
- 272 g
- Environmental Parameters - Humidity Range Operating
- 5 - 95% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 40 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Interfaces
- 1 x 1000Base-T (PoE) - RJ-45
- General - Depth
- 12.4 cm
- General - Device Type
- Radio access point
- General - Height
- 2.58 cm
- General - Weight
- 272 g
- General - Width
- 20.2 cm
- Internet of Things (IoT) - Communications Technology
- Bluetooth Low Energy (LE)
- Internet of Things (IoT) - Internet of Things (IoT) Compatible
- Yes
- Manufacturer Warranty - Service & Support
- Limited warranty - advanced replacement - lifetime
- Miscellaneous - Compliant Standards
- CSA, VCCI, ICES-003, EN55024, CISPR 22, FCC Part 15 B, RSS-102, FCC Part 15 C, UL 2043, RoHS, FCC Part 2, AS/NZS 4268, FCC Part 15 E, EN 62311, EN 300 328, EN 50385, RSS-247, EN 301 489-1-17, EN 62479, EN 301 893, EN 55032, AS/NZS 2772, CB 60950, CB 62368, IFT, NOM-208, NCC LP0002
- Miscellaneous - MTBF
- 257,215 hours
- Networking - Authentication Method
- MS-CHAP v.2, EAP-SIM, EAP-TLS, EAP-TTLS
- Networking - Cloud-Managed
- Yes
- Networking - Compliant Standards
- IEEE 802.1Q, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3af, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11n, IEEE 802.11k, IEEE 802.11ac, IEEE 802.11r, IEEE 802.11u, IEEE 802.11ax
- Networking - Connectivity Technology
- Wireless
- Networking - Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac Wave 2, Bluetooth 5.0 LE, IEEE 802.11ax (Wi-Fi 6)
- Networking - Data Transfer Rate
- 1.5 Gbps
- Networking - Encryption Algorithm
- AES, TKIP, WPA, WPA2-PSK, WPA2-Enterprise, WEP, WPA3-Enterprise, WPA3-Personal, WPA3-Enhanced Open
- Networking - Features
- Firewall protection, VPN support, firmware upgradable, tunnelling, Wi-Fi Multimedia (WMM) support, Quality of Service (QoS), Maximum Ratio Combining (MRC), DiffServ Code Point (DSCP) support, Bluetooth Low Energy Beaconing, Unscheduled Automatic Power Save Delivery (U-APSD), beamforming technology, SU-MIMO technology, PMK Caching, guest access, layer 3 roaming, opportunistic key caching (OKC), VLAN Tagging, 2x2:2 MU-MIMO technology, packet aggregation, layer 2 roaming, Orthogonal Frequency Division Multiple Access (OFDMA), BSS Coloring, Target Wake Time (TWT), Enterprise Mobility Management (EMM), Mobile Device Management (MDM), Cisco ISE integration, layer 7 application traffic identification and shaping, global L7 traffic analytics, embedded location analytics reporting and device tracking
- Networking - Form Factor
- External
- Networking - Frequency Band
- 2.4 GHz, 5 GHz
- Networking - Line Coding Format
- 1024 QAM
- Networking - Network / Transport Protocol
- IPSec
- Networking - Performance
- Maximum data rate (5 GHz): 1201 Mbps ¦ Maximum data rate (2.4 GHz): 286 Mbps
- Networking - Status Indicators
- Power, Boot State, firmware
- Power - Power Over Ethernet (PoE) Supported
- PoE
