- Basic Specifications - EAN
- 4711377269995
- Basic Specifications - Manufacturer's Part Number
- 125666
- External connectivity - Audio
- 7.1-Channel High-Definition Audio
- External connectivity - LAN
- - Intel® Wi-Fi 7- Bluetooth 5.4
- External connectivity - USB
- - USB Type-C x 1- USB Type-A x 6
- External connectivity - Video output
- - HDMI 2.1 x 1- DisplayPort 1.4 x 1
- General - Box contents
- - MSI PRO Z890-S WIFI LGA1851 Motherboard- Regulatory Notice- Guide- EZ M.2 clip remover- M.2 clip x 3- EZ Wifi Antenna- SATA Cables x 2
- General - Colour
- Black
- General - Dimensions
- 70 x 270 x 345 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Weight
- 1.65 kg
- Internal connectivity - BIOS
- Click BIOS X
- Internal connectivity - Buttons
- Power button
- Internal connectivity - Cooling
- - CPU fan 4-pin x 1- Combo fan x 1- System fan 4-pin x 4
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16 slot) x 1- PCIe 4.0 (x4 slot) x 2- PCIe 3.0 (x1 slot) x 1
- Internal connectivity - Other internal connections
- - Thunderbolt5 card connector x 1- CPU Fan x 1- Front Panel (JFP) x 2- Chassis Intrusion (JCI) x 1- Tuning Controller connector x 1- Addressable V2 RGB LED connector (JARGB_V2) x 3- RGB LED connector (JRGB) x 1- TPM pin header (Support TPM 2.0) x 1
- Internal connectivity - Power
- - 24-pin ATX x 1- 8-pin 12V ATX x 1
- Internal connectivity - Sensors
- Thermal sensor
- Internal connectivity - Storage slots
- - SATA x 4 (6 GB/s) - M.2 x 3 (64 GB/s)
- Internal connectivity - USB
- - USB Type-C x 1- USB 3.2 x 2- USB 2.0 x 4
- Overview - Chipset
- Intel® Z890
- Overview - Cooling features
- Frozr AI cooling
- Overview - Form factor
- ATX
- Overview - Memory slots
- 4 x UDIMM (Max RAM: 256 GB)
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- Windows 11 or later
- Overview - Processor models supported
- Intel® Core™ Ultra Processors (Series 2)
- Overview - Socket
- Intel® LGA1851
