- Basic Specifications - Dimensions (WxDxH)
- 20 cm x 7.5 cm x 3 cm
- Basic Specifications - Docking Interface
- Thunderbolt 4
- Basic Specifications - EAN
- 0732311013157
- Basic Specifications - Manufacturer Warranty
- 2-year warranty
- Basic Specifications - Manufacturer's Part Number
- ECHO-DK11-T4
- Basic Specifications - Model
- Sonnet Echo 11
- Basic Specifications - Monitor Inputs
- Memory card
- Basic Specifications - Networking
- Gigabit Ethernet
- Basic Specifications - Power
- Power adapter
- Basic Specifications - Product Description
- Sonnet Echo 11 - docking station - Thunderbolt 4 - 3 x Thunderbolt - 1GbE
- Basic Specifications - Product Type
- Docking Station
- Basic Specifications - Video Interfaces
- 3 x Thunderbolt
- Dimensions & Weight (Shipping) - Shipping Weight
- 1.5 kg
- Environmental Parameters - Max Operating Temperature
- 35 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Expansion Slots
- 1 (total) / 1 (free) x SDXC Memory Card
- Expansion / Connectivity - Interfaces
- 4 x Thunderbolt 4 - 24 pin USB-C ¦ 3 x USB 3.2 Gen 2 - 9 pin USB Type A ¦ 1 x PoweredUSB 2.0 - 4 pin USB Type A ¦ 1 x network - 10Base-T/100Base-TX/1000Base-TX - RJ-45 ¦ 1 x headphone/microphone combo jack - mini-phone 3.5 mm
- General - Depth
- 7.5 cm
- General - Height
- 3 cm
- General - Product Type
- Docking station
- General - Width
- 20 cm
- Manufacturer Warranty - Service & Support
- Limited warranty - 2 years
- Miscellaneous - Cables Included
- 1 x Thunderbolt 4 cable - 70 cm
- Miscellaneous - Compliant Standards
- UL, VCCI, FCC Part 15 B, PSE Mark, CISPR32/EN55032, IEC 62368-1, Directive 2015/863, RoHS3, IEC 62368-2
- Miscellaneous - Features
- 90W power delivery, RTL8153B chipset
- Networking - Data Link Protocol
- Gigabit Ethernet
- Power - Power Device
- Power adapter
- System Requirements - OS Required
- Windows 10 (64-bit Version 20H2) or later, Apple macOS Big Sur 11.2 or later
