- Aerial - Antenna
- Internal
- Aerial - Directivity
- Omni-directional
- Basic Specifications - Capacity
- Maximum number of configured SSIDs (2.4 Ghz): 8 ¦ Maximum number of configured SSIDs (5 Ghz): 8 ¦ Number of concurrent clients: 250+ ¦ MAC filter entries: 4000
- Basic Specifications - Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax
- Basic Specifications - Device Type
- Radio access point
- Basic Specifications - Dimensions (WxDxH)
- 24.3 cm x 24.3 cm x 6.4 cm
- Basic Specifications - EAN
- 4897098681510
- Basic Specifications - Form Factor
- Wall / ceiling mountable
- Basic Specifications - Frequency Band
- 2.4 GHz, 5 GHz
- Basic Specifications - Included Accessories
- Wall/ceiling mounting kit
- Basic Specifications - Manufacturer's Part Number
- EAP670
- Basic Specifications - Model
- TP-Link Omada EAP670 V1.26
- Basic Specifications - OS Required
- Linux, Microsoft Windows XP / Vista / 7 / 8 / 10
- Basic Specifications - Performance
- Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 4804 Mbps ¦ Channel bandwidth: 160 MHz
- Basic Specifications - Power
- DC 12 V
- Basic Specifications - Power Over Ethernet (PoE) Supported
- PoE+
- Basic Specifications - Product Description
- TP-Link Omada EAP670 V1.26 - radio access point - Wi-Fi 6 - cloud-managed
- Environmental Parameters - Humidity Range Operating
- 10 - 90% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 40 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Interfaces
- 1 x 2.5 GBase-T (PoE+) - RJ-45
- General - Depth
- 24.3 cm
- General - Device Type
- Radio access point
- General - Height
- 6.4 cm
- General - Width
- 24.3 cm
- Miscellaneous - Compliant Standards
- FCC, RoHS
- Miscellaneous - Included Accessories
- Wall/ceiling mounting kit
- Networking - Authentication Method
- Secure Shell (SSH), Radio Service Set ID (SSID)
- Networking - Capacity
- Maximum number of configured SSIDs (2.4 Ghz): 8 ¦ Maximum number of configured SSIDs (5 Ghz): 8 ¦ Number of concurrent clients: 250+ ¦ MAC filter entries: 4000
- Networking - Cloud-Managed
- Yes
- Networking - Compliant Standards
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.1x, IEEE 802.11n, IEEE 802.3at, IEEE 802.11ac, IEEE 802.11ax, Wi-Fi CERTIFIED 6
- Networking - Connectivity Technology
- Wireless
- Networking - Data Link Protocol
- IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 802.11ax
- Networking - Encryption Algorithm
- WPA-Enterprise, WPA2-Enterprise, WPA3-Enterprise, WPA3-Personal, WPA2-Personal, WPA-Personal
- Networking - Features
- Load balancing, Syslog support, E-mail alert, MAC address filtering, Quality of Service (QoS), reset button, rogue access point detection, Captive Portal, Transmit Power Control (TPC), MU-MIMO technology, beamforming technology, band steering, SSID to VLAN mapping, rate limit, Wireless Scheduler, Software Defined Networking (SDN), wireless SSID, VLAN management, LED on/off button, Extensive Access Control List (ACL) support, seamless roaming, Airtime Fairness, Zero-touch provisioning (ZTP), client isolation, schedule reboot, Omada Mesh technology, multi-site management
- Networking - Form Factor
- Wall / ceiling mountable
- Networking - Frequency Band
- 2.4 GHz, 5 GHz
- Networking - Line Coding Format
- OFDM, 1024 QAM, OFDMA
- Networking - Network / Transport Protocol
- HTTP, HTTPs
- Networking - Performance
- Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 4804 Mbps ¦ Channel bandwidth: 160 MHz
- Networking - Remote Management Protocol
- SNMP 1, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH
- Networking - Spread Spectrum Method
- OFDM, OFDMA
- Networking - Status Indicators
- Status
- Networking - Wi-Fi Rating
- AX5400
- Power - Power Consumption Operational
- 15 Watt
- Power - Power Device
- External power adapter
- Power - Power Over Ethernet (PoE) Supported
- PoE+
- Power - Voltage Required
- DC 12 V
- Software / System Requirements - OS Required
- Linux, Microsoft Windows XP / Vista / 7 / 8 / 10
- Software / System Requirements - Software Included
- Omada Controller
