- Basic Specifications - EAN
- 4711377290616
- Basic Specifications - Manufacturer's Part Number
- 126155
- External connectivity - Audio
- - Realtek® ALC897 Codec- 7.1-Channel High-Definition Audio
- External connectivity - LAN
- - Realtek® 8126 5G LAN- Bluetooth 5.4
- External connectivity - USB
- - USB Type-C (20Gbps) x 1- USB Type-C (10Gbps) x 2- USB Type-A (10Gbps) x 3- USB Type-A (5Gbps) x 5- USB 2.0 x 8
- External connectivity - Video output
- - HDMI 2.1 x 1- DisplayPort 1.4 x 1
- General - Box contents
- - MSI MPG B850 EDGE TI WIFI AM5 Motherboard- EZ Wi-Fi Antenna- EZ M.2 Clip II x 3- EZ M.2 Clip II Remover- SATA Cable- ARGB Extension Cable- M.2 Screw Package x 2- Wi-Fi Antenna- Cable Stickers- SATA Cables x 2- EZ M.2 Clip Package x 2- EZ Conn-Cable (V2) 1 to 3- EZ Front Panel Cable- Quick Installation Guide
- General - Colour
- Black
- General - Dimensions
- 73 x 243 x 304 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- Internal connectivity - BIOS
- Flash BIOS
- Internal connectivity - Buttons
- Clear CMOS Button
- Internal connectivity - Cooling
- - CPU fan x 1- System fan x 6- Pump fan x 1
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16) x 1- PCIe 4.0 (x16) x 1- PCIe 3.0 (x16) x 1
- Internal connectivity - Other internal connections
- - RGB LED connector x 2- Addressable V2 RGB connector x 2- TPM header x 1- EZ Debug LED x 4
- Internal connectivity - Power
- - Power Connector (ATX_PWR) x 1- Power Connector (CPU_PWR) x 2- Power Connector (PCIE_PWR 8pin) x 1
- Internal connectivity - Storage slots
- - SATA x 4 (6 GB/s)- M.2 Gen4 x 1 (32 GB/s)- M.2 Gen4 x 1 (64 GB/s)- M.2 Gen5 X 2 (128 GB/s)
- Overview - Chipset
- AMD B850
- Overview - Cooling features
- - Extended heatsink design- EZ PCIe release- EZ M.2 Shield Frozr II- Smart fan - 2oz Thickened Copper PC- MOFSET thermal pads- Pump fan support
- Overview - Form factor
- ATX
- Overview - Memory slots
- 4 x UDIMM (Max RAM: 256 GB)
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- Windows 11
- Overview - Processor models supported
- AMD Ryzen 9000, 8000 & 7000 Series desktop processors
- Overview - Socket
- AMD AM5
