- Audio Input - Microphone Operation Mode
- Beamforming
- Audio Input - Type
- 16-microphone array - integrated
- Audio Output - Frequency Response
- 70 - 22000 Hz
- Audio Output - Sound Output Mode
- Stereo
- Audio Output - Type
- Speaker(s)
- Basic Specifications - Audio Input
- 16-microphone array - beamforming
- Basic Specifications - Audio Output
- Speaker(s) - stereo
- Basic Specifications - Bundled with
- Cisco Room Navigator-Table Stand
- Basic Specifications - Codec
- H.265, H.264, H.263, H.239, G.711, G.722, G.722.1, G.729, AAC-LD, Opus
- Basic Specifications - Data Compression Protocol
- H.239
- Basic Specifications - Device Type
- Video conferencing device
- Basic Specifications - Digital Signaling Protocol
- H.460.18, H.460.19, H.239, BFCP, SIP, H.323, H.245
- Basic Specifications - Dimensions (WxDxH)
- 96 cm x 9 cm x 11 cm
- Basic Specifications - EAN
- 0889728537858
- Basic Specifications - Manufacturer Warranty
- 90 days warranty
- Basic Specifications - Manufacturer's Part Number
- CS-BARPRO-C-K9
- Basic Specifications - Model
- Cisco Webex Room Bar Pro
- Basic Specifications - Networking
- Bluetooth, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E)
- Basic Specifications - Power
- AC 100-240 V (50/60 Hz)
- Basic Specifications - Product Description
- Cisco Webex Room Bar Pro - video conferencing device - with Cisco Room Navigator-Table Stand
- Basic Specifications - Video Input
- Dual digital video camera - HDMI output, HDMI input, DisplayPort input
- Basic Specifications - VoIP Protocols
- SIP, H.323, H.245, SRTP
- Basic Specifications - Weight
- 4.47 kg
- Dimensions & Weight (Shipping) - Shipping Depth
- 22.7 cm
- Dimensions & Weight (Shipping) - Shipping Height
- 23.3 cm
- Dimensions & Weight (Shipping) - Shipping Weight
- 8.9 kg
- Dimensions & Weight (Shipping) - Shipping Width
- 112.6 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 90% RH
- Environmental Parameters - Max Operating Temperature
- 35 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Interfaces
- 1 x audio / video - HDMI input - 19 pin HDMI Type A ¦ 1 x audio - line-in/microphone - mini-phone stereo 3.5 mm ¦ 1 x USB-C / DisplayPort - 24 pin USB-C ¦ 1 x USB - input / output - 9 pin USB Type A ¦ 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 3 x network - Ethernet 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45 ¦ 2 x USB 2.0 - input - 9 pin USB Type A ¦ 1 x USB - 5 pin Micro-USB Type A
- General - Built-in Devices
- Presence sensor
- General - Bundled with
- Cisco Room Navigator-Table Stand
- General - Depth
- 9 cm
- General - Device Type
- Video conferencing device
- General - Enclosure Colour
- Carbon
- General - Height
- 11 cm
- General - IP Address Assignment
- DHCP
- General - Network Protocols
- SIP, DNS, NTP, DHCP, IPv4, IPv6, HTTP, HTTPS, TLS, Cisco Discovery Protocol (CDP), SSH, SRTP
- General - Quality of Service
- IEEE 802.1Q (VLAN), IEEE 802.1p
- General - Security
- H.323, H.235 v3, AES, TLS, IEEE 802.1X, SRTP, WPA3, 256 bit AES, 128 bit AES
- General - Video Codecs
- H.265, H.264, H.263, H.239
- General - Voice Codecs
- G.711, G.722, G.722.1, G.729, AAC-LD, Opus
- General - VoIP Protocols
- SIP, H.323, H.245, SRTP
- General - Weight
- 4.47 kg
- General - Width
- 96 cm
- Manufacturer Warranty - Service & Support
- Limited warranty - 90 days
- Miscellaneous - Cables Included
- 1 x network cable - 8 m ¦ 1 x network cable - 5 m ¦ 1 x HDMI cable - 1.5 m
- Miscellaneous - Compliant Standards
- WEEE, CEC 2.0, IEEE 802.1x, AES-128, AES-256, MIC, Directive 2014/53/EU, Directive 2014/30/EU, Directive 2014/35/EU, Directive 2011/65/EU, Directive 2012/19/EU, NRTL, FCC 47 CFR Part 15 B Class A, FCC CFR 47 Part 15C, FCC CFR 47 Part 15E, FCC
- Miscellaneous - Mounting Kit
- Included
- Modem - Data Compression Protocol
- H.239
- Modem - Digital Signaling Protocol
- H.460.18, H.460.19, H.239, BFCP, SIP, H.323, H.245
- Networking - Compliant Standards
- IEEE 802.1x, IEEE 802.1Q, IEEE 802.1p
- Networking - Connectivity Technology
- Wireless, wired
- Networking - Data Link Protocol
- Bluetooth, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E)
- Networking - Features
- Cisco Expressway technology, Wireless Screen Sharing, Apple AirPlay, Wi-Fi Miracast ready, WebRTC, Quality of Service (QoS), flow control, auto gatekeeper discovery, DTMF support, URI Dialing, DiffServ support, static IP mode, password protection, Certificate Authority Proxy Function (CAPF), 2x2 MIMO technology
- Networking - Network / Transport Protocol
- DNS, NTP, DHCP, IPv4, IPv6, HTTP, HTTPs
- Networking - Performance
- Bandwidth: 20 Mbps
- Power - Power Consumption Operational
- 12.7 Watt
- Power - Power Device
- Power supply - external
- Power - Voltage Required
- AC 100-240 V (50/60 Hz)
- Software / System Requirements - Software Included
- RoomOS 11.5.1.x or later
- Video Input - Digital Video Capture Resolution
- 3840 x 2160, 1920 x 1080
- Video Input - Digital Zoom
- 5
- Video Input - Features
- AI-powered, 96 megapixels resolution, 112° horizontal field of view (wide), 70° horizontal field of view (tele), intelligent picture framing, noise-cancellation, motorised tilt, 30 fps, 1/1.3" quad bayer, F 2.8 lens aperture, 94° vertical field of view (wide), 55° vertical field of view (tele), auto-framing, speaker tracking, automatic brightness adjustment, auto white balance, LED indicator, Acoustic Echo Cancellation (AEC), auto AGC, dereverberation, full duplex audio, self-hear, spatial audio, Ultrasound technology
- Video Input - Interface Type
- HDMI output, HDMI input, DisplayPort input
- Video Input - Type
- Dual digital video camera (colour) - integrated
- Video Input - Video Modes
- 1080/60p, 4K/30p
