- Aerial - Aerial
- External detachable
- Aerial - Antenna Qty
- 2
- Basic Specifications - Capacity
- VPN tunnels: 2 ¦ Number of web portal users: 4 ¦ VLANs supported: 8 ¦ LAN Subnet supported: 4 ¦ NAT sessions: 50000
- Basic Specifications - Compliant Standards
- IEEE 802.1p, IEEE 802.1x, IEEE 802.1Q, ITU-T G.998.4, ITU-T G.993.1
- Basic Specifications - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet
- Basic Specifications - Device Type
- Router - DSL modem - 4-port switch (integrated)
- Basic Specifications - Digital Signaling Protocol
- ADSL2+, VDSL2
- Basic Specifications - Dimensions (WxDxH)
- 20.7 cm x 13.1 cm x 4.2 cm
- Basic Specifications - EAN
- 4710484745330
- Basic Specifications - Enclosure Type
- Desktop, wall-mountable
- Basic Specifications - Features
- IPFIX, e-mail notification, SMS alert, ACL support, Brute Force Protection, 2-Level Administration Privilege, remote firmware upgrade, Syslog support, QoS, VoIP support, ToS, DSCP prioritisation, IP address filtering, spoofing defence, DoS attack prevention, content filtering, IP-based Firewall Policy, VPN support, RTSP support, SIP ALG, NAT port redirection, NAT support, port triggering, DMZ host, UPnP, VPN Matcher, IPSec NAT-T, Single-Armed VPN, PSK, PPTP client, PPTP passthrough, L2TP over IPSec, Teleworker-to-LAN bridging, LAN-to-LAN bridging, file sharing, IGMP proxy, IGMP snooping, IGMP fast leave, DNSSEC support, IPv4 support, IPv6 support, Inter-VLAN Routing, DNS server, port mirroring, 802.1x authentication, DHCP server, multiple IP settings, port-based VLAN, DrayDDNS, dynamic DNS, WAN Budget, ARP detect, ping detect, failover protection, VLAN Tagging, VDSL2 profile management, reset button, H.323 Pass-Through
- Basic Specifications - Localisation
- United Kingdom, Ireland
- Basic Specifications - Manufacturer Warranty
- 2-year warranty
- Basic Specifications - Manufacturer's Part Number
- V2763-K
- Basic Specifications - Model
- Draytek Vigor 2763
- Basic Specifications - Network / Transport Protocol
- FTP, IPSec, L2TP, PPTP, RTSP, OpenVPN, WireGuard, PPPoE, PPPoA, DHCP
- Basic Specifications - Performance
- VPN throughput (SSL): 100 Mbps ¦ VPN throughput (256-bit AES IPSec): 150 Mbps ¦ NAT throughput with hardware acceleration: 940 Mbps ¦ NAT throughput without hardware acceleration: 400 Mbps
- Basic Specifications - Power
- DC 12 V 1.3 A
- Basic Specifications - Product Description
- Draytek Vigor 2763 - router - DSL modem - desktop, wall-mountable
- Basic Specifications - Remote Management Protocol
- Syslog, SNMP 1, SNMP 2c, SNMP 3, HTTP, TFTP, TR-069, HTTPS, Telnet, SSH-2
- Basic Specifications - Routing Protocol
- IGMPv3, IGMPv2, policy-based routing (PBR), static IP routing, static IPv4 routing, static IPv6 routing, RIP-1, RIP-2, MPOA
- Basic Specifications - WAN Ports Qty
- 1
- Basic Specifications - Weight
- 450 g
- Communications - Digital Signaling Protocol
- ADSL2+, VDSL2
- Communications - Protocols & Specifications
- T1.413 Issue 2, ITU G.992.2 (G.Lite), ITU G.992.1 (G.DMT), ITU G.993.1, ITU G.993.2 Annex A, ITU G.993.2 Annex B, ITU G.993.2 Annex M, ITU G.993.2 Annex Q, ITU G.997.1
- Communications - Type
- DSL modem
- Dimensions & Weight - Depth
- 13.1 cm
- Dimensions & Weight - Height
- 4.2 cm
- Dimensions & Weight - Weight
- 450 g
- Dimensions & Weight - Width
- 20.7 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 90% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 45 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Interfaces
- LAN: 3 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 1 x VDSL2 / ADSL2+ - RJ-11 ¦ USB 2.0: 2 x 4 pin USB Type A ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45
- General - Authentication Method
- X.509 certificates, RADIUS, Mobile One Time Password (mOTP), XAUTH authentication, Extensible Authentication Protocol (EAP)
- General - Capacity
- VPN tunnels: 2 ¦ Number of web portal users: 4 ¦ VLANs supported: 8 ¦ LAN Subnet supported: 4 ¦ NAT sessions: 50000
- General - Compliant Standards
- IEEE 802.1p, IEEE 802.1x, IEEE 802.1Q, ITU-T G.998.4, ITU-T G.993.1
- General - Connectivity Technology
- Wired
- General - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet
- General - Device Type
- Router - 4-port switch (integrated)
- General - Enclosure Type
- Desktop, wall-mountable
- General - Encryption Algorithm
- MPPE, DES, 3DES, AES, MD5, SHA-1, SHA-256, SSL, IKEv2
- General - Features
- IPFIX, e-mail notification, SMS alert, ACL support, Brute Force Protection, 2-Level Administration Privilege, remote firmware upgrade, Syslog support, QoS, VoIP support, ToS, DSCP prioritisation, IP address filtering, spoofing defence, DoS attack prevention, content filtering, IP-based Firewall Policy, VPN support, RTSP support, SIP ALG, NAT port redirection, NAT support, port triggering, DMZ host, UPnP, VPN Matcher, IPSec NAT-T, Single-Armed VPN, PSK, PPTP client, PPTP passthrough, L2TP over IPSec, Teleworker-to-LAN bridging, LAN-to-LAN bridging, file sharing, IGMP proxy, IGMP snooping, IGMP fast leave, DNSSEC support, IPv4 support, IPv6 support, Inter-VLAN Routing, DNS server, port mirroring, 802.1x authentication, DHCP server, multiple IP settings, port-based VLAN, DrayDDNS, dynamic DNS, WAN Budget, ARP detect, ping detect, failover protection, VLAN Tagging, VDSL2 profile management, reset button, H.323 Pass-Through
- General - Network / Transport Protocol
- FTP, IPSec, L2TP, PPTP, RTSP, OpenVPN, WireGuard, PPPoE, PPPoA, DHCP
- General - Performance
- VPN throughput (SSL): 100 Mbps ¦ VPN throughput (256-bit AES IPSec): 150 Mbps ¦ NAT throughput with hardware acceleration: 940 Mbps ¦ NAT throughput without hardware acceleration: 400 Mbps
- General - Remote Management Protocol
- Syslog, SNMP 1, SNMP 2c, SNMP 3, HTTP, TFTP, TR-069, HTTPS, Telnet, SSH-2
- General - Routing Protocol
- IGMPv3, IGMPv2, policy-based routing (PBR), static IP routing, static IPv4 routing, static IPv6 routing, RIP-1, RIP-2, MPOA
- Manufacturer Warranty - Service & Support
- Limited warranty - 2 years
- Miscellaneous - Cables Included
- 1 x network cable - 2 m
- Miscellaneous - Included Accessories
- Wall mounting kit
- Miscellaneous - Localisation
- United Kingdom, Ireland
- Power - Electric Current Required
- 1.3 A
- Power - Power Consumption Operational
- 14.6 Watt
- Power - Power Device
- External power adapter
- Power - Voltage Required
- DC 12 V
- Software / System Requirements - OS Provided
- No operating system
- Software / System Requirements - Software Included
- VigorACS Management
