- Basic Specifications - Capacity
- VLANs supported: 16 ¦ Concurrent VPN tunnels: 32 ¦ NAT sessions: 60000 ¦ Concurrent SSL VPN tunnels: 16
- Basic Specifications - Compliant Standards
- ANSI T1.413, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, UPnP
- Basic Specifications - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, PPP
- Basic Specifications - Device Type
- Router - DSL modem
- Basic Specifications - Digital Signaling Protocol
- VDSL2, ADSL2+, Vplus 35b, ADSL2, ADSL, VDSL
- Basic Specifications - Dimensions (WxDxH)
- 24.1 cm x 16.6 cm x 4.6 cm
- Basic Specifications - EAN
- 4710484741257
- Basic Specifications - Enclosure Type
- Desktop
- Basic Specifications - Features
- Firewall protection, 3G/4G USB Dongle Support, VPN support, reset button, load balancing, content filtering, DynDNS, bandwidth control, DHCP server, IPv6 support, IPv4 support, VLAN Tagging, ARP support, port-based VLAN, IP-MAC binding, port mirroring, DNS server, High Availability, IGMP proxy, IGMP snooping, file sharing, LAN-to-LAN bridging, GRE, IPSec NAT-T, failover protection, port triggering, DMZ support, ALG support, VPN passthrough, application filtering, URL filtering, Web Filtering, anti-spoofing protection, DoS attack prevention, QoS, ToS, DSCP support, DSCP based ToS, ACL support, Brute Force Protection, E-mail alert, SMS alert, Syslog support, tagged VLAN, keyword filtering
- Basic Specifications - Localisation
- United Kingdom, Ireland
- Basic Specifications - Manufacturer Warranty
- 2-year warranty
- Basic Specifications - Manufacturer's Part Number
- V2865-K
- Basic Specifications - Model
- Draytek Vigor 2865
- Basic Specifications - Network / Transport Protocol
- IPSec, DDNS, DHCP, PPPoE, PPTP, L2TP, IPv4, IPv6, DHCPv6, Bonjour, SMB, RTSP, FTP
- Basic Specifications - Performance
- VPN throughput (256-bit AES IPSec): 300 Mbps ¦ VPN throughput (SSL): 120 Mbps ¦ NAT throughput: 800 Mbps
- Basic Specifications - Product Description
- Draytek Vigor 2865 - router - DSL modem - desktop
- Basic Specifications - Remote Management Protocol
- Telnet, HTTP, HTTPS, SSH, TR-069, TFTP, SNMP 1, SNMP 2c, SNMP 3
- Basic Specifications - Routing Protocol
- Static IPv4 routing, static IPv6 routing, RIP, BGP, policy-based routing (PBR), GRE
- Basic Specifications - VoIP Protocols
- SIP, H.323
- Basic Specifications - WAN Ports Qty
- 2
- Basic Specifications - Weight
- 620 g
- Communications - Digital Signaling Protocol
- VDSL2, ADSL2+, Vplus 35b, ADSL2, ADSL, VDSL
- Communications - Max Transfer Rate
- 300 Mbps
- Communications - Protocols & Specifications
- ITU G.993.2, ITU G.993.5, ITU G.992.1 (G.DMT) Annex A, ITU G.992.3 Annex A, ITU G.992.5 Annex A
- Communications - Type
- DSL modem
- Dimensions & Weight - Depth
- 16.6 cm
- Dimensions & Weight - Height
- 4.6 cm
- Dimensions & Weight - Weight
- 620 g
- Dimensions & Weight - Width
- 24.1 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 90% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 45 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Expansion / Connectivity - Interfaces
- LAN: 5 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN / LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ WAN: 1 x VDSL2 / ADSL2+ - RJ-11 ¦ USB 2.0: 2 x 4 pin USB Type A
- General - Authentication Method
- RADIUS, XAUTH authentication, internal user database, LDAP, TACACS+, X.509 certificates
- General - Built-in Devices
- Led panel
- General - Capacity
- VLANs supported: 16 ¦ Concurrent VPN tunnels: 32 ¦ NAT sessions: 60000 ¦ Concurrent SSL VPN tunnels: 16
- General - Compliant Standards
- ANSI T1.413, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, UPnP
- General - Connectivity Technology
- Wired
- General - Data Link Protocol
- Ethernet, Fast Ethernet, Gigabit Ethernet, PPP
- General - Device Type
- Router
- General - Enclosure Type
- Desktop
- General - Encryption Algorithm
- SSL, IKEv2, SHA-1, 256-bit SHA, DES, Triple DES, AES, MPPE
- General - Features
- Firewall protection, 3G/4G USB Dongle Support, VPN support, reset button, load balancing, content filtering, DynDNS, bandwidth control, DHCP server, IPv6 support, IPv4 support, VLAN Tagging, ARP support, port-based VLAN, IP-MAC binding, port mirroring, DNS server, High Availability, IGMP proxy, IGMP snooping, file sharing, LAN-to-LAN bridging, GRE, IPSec NAT-T, failover protection, port triggering, DMZ support, ALG support, VPN passthrough, application filtering, URL filtering, Web Filtering, anti-spoofing protection, DoS attack prevention, QoS, ToS, DSCP support, DSCP based ToS, ACL support, Brute Force Protection, E-mail alert, SMS alert, Syslog support, tagged VLAN, keyword filtering
- General - Network / Transport Protocol
- IPSec, DDNS, DHCP, PPPoE, PPTP, L2TP, IPv4, IPv6, DHCPv6, Bonjour, SMB, RTSP, FTP
- General - Performance
- VPN throughput (256-bit AES IPSec): 300 Mbps ¦ VPN throughput (SSL): 120 Mbps ¦ NAT throughput: 800 Mbps
- General - Remote Management Protocol
- Telnet, HTTP, HTTPS, SSH, TR-069, TFTP, SNMP 1, SNMP 2c, SNMP 3
- General - Routing Protocol
- Static IPv4 routing, static IPv6 routing, RIP, BGP, policy-based routing (PBR), GRE
- General - Status Indicators
- DMZ, DSL, link/activity, USB, VPN, WAN
- IP Telephony - VoIP Protocols
- SIP, H.323
- Line Properties - Framing Format
- ANSI T1.413
- Manufacturer Warranty - Service & Support
- Limited warranty - 2 years
- Miscellaneous - Cables Included
- 1 x modem cable
- Miscellaneous - Localisation
- United Kingdom, Ireland
- Power - Power Device
- External power adapter
- Software / System Requirements - OS Provided
- No operating system
