- Basic Specifications - EAN
- 4719331869908
- Basic Specifications - Manufacturer's Part Number
- 127357
- External connectivity - Audio
- 3.5 mm jack x 3
- External connectivity - LAN
- Realtek GbE LAN
- External connectivity - Other external connections
- PS2 keyboard, mouse, Wi-Fi antenna connectors x2
- External connectivity - USB
- - USB 3.2 Gen 2 Type-A: 2
- External connectivity - Video output
- HDMI x 1
- General - Box contents
- - Gigabyte DS3H AC R2 B550 AM4 Motherboard- Manual- Antenna- IO Shield- SATA cables x 2
- General - Colour
- Black
- General - Dimensions
- 70 x 244 x 244 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Weight
- 1100 g
- Internal connectivity - BIOS
- - UEFI AMI BIOS- 128 Mbit flash - PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- Internal connectivity - Buttons
- - Q-Flash Plus x 1- Clear CMOS jumper x 1
- Internal connectivity - Cooling
- - CPU fan header x 1- System fan headers x 2- Fan speed detection- Smart Fan 6
- Internal connectivity - Expansion slots
- - PCIe 4.0 (x16) x 1- PCIe 3.0 (x16) x 1
- Internal connectivity - Other internal connections
- - Front panel header x 1- Front panel audio header x 1- Addressable RGB Gen2 LED Strip Headers x 2- RGB LED Strip Header x 2- Trusted Platform Module header x 1
- Internal connectivity - Power
- - 24-pin ATX x 1- 8-pin ATX x 1- 4-pin ATX x 1
- Internal connectivity - Sensors
- - Voltage- Temperature- Fan speed
- Internal connectivity - Storage slots
- - SATA x 4- M.2 x 2
- Internal connectivity - USB
- - USB Type-C x 1 - USB 3.2 Gen 1 x 4- USB 2.0/1.1 x 4
- Overview - Chipset
- AMD B550
- Overview - Cooling features
- - Heatsink- VRM Thermal Armor Advanced- AMD StoreMI
- Overview - Form factor
- Micro ATX
- Overview - Memory slots
- 4 x DIMM (Max RAM: 128 GB)
- Overview - Memory standard
- DDR4
- Overview - Operating systems supported
- Windows 11 (64-bit)
- Overview - Processor models supported
- AMD Ryzen 3000, 4000 & 5000 Series processors
- Overview - Socket
- AMD AM4
