- Audio - Audio Codec
- Realtek ALC892
- Audio - Compliant Standards
- High Definition Audio
- Audio - Type
- HD Audio (8-channel)
- Basic Specifications - Audio
- HD Audio (8-channel)
- Basic Specifications - Chipset Type
- AMD A520
- Basic Specifications - Compatible Processors
- Ryzen (supports 3rd Generation Ryzen and Ryzen 4000 G-Series)
- Basic Specifications - EAN
- 4719072749927
- Basic Specifications - Form Factor
- Micro ATX
- Basic Specifications - LAN
- Gigabit Ethernet
- Basic Specifications - Manufacturer's Part Number
- A520M-A PRO
- Basic Specifications - Max Allocated RAM Size
- 16 GB
- Basic Specifications - Max RAM Size
- 64 GB
- Basic Specifications - Model
- MSI A520M-A PRO
- Basic Specifications - Processor Socket
- AMD AM4
- Basic Specifications - Product Description
- MSI A520M-A PRO - motherboard - micro ATX - Socket AM4 - AMD A520
- Basic Specifications - Product Type
- Motherboard - micro ATX
- Basic Specifications - RAM Supported
- 2 DIMM slots - DDR4, non-ECC, ECC (operate in non-ECC mode), unbuffered
- Basic Specifications - Storage Ports
- 4 x SATA-600 (RAID), 1 x M.2
- Basic Specifications - USB / FireWire Ports
- 4 x USB 3.2 Gen 1 + 2 x USB 2.0 + (2 x USB 3.2 Gen 1 + 4 x USB 2.0 via headers)
- Expansion / Connectivity - Expansion Slots
- 1 x CPU ¦ 2 x DIMM 288-pin ¦ 1 x PCIe x16 ¦ 1 x PCIe 3.0 x1
- Expansion / Connectivity - Interfaces
- 1 x LAN (Gigabit Ethernet) ¦ 1 x audio line-in - mini-jack ¦ 1 x audio line-out - mini-jack ¦ 1 x microphone - mini-jack ¦ 4 x USB 3.2 Gen 1 ¦ 1 x PS/2 mouse ¦ 2 x USB 2.0 ¦ 1 x HDMI ¦ 1 x DVI-D ¦ 1 x PS/2 keyboard
- Expansion / Connectivity - Internal Interfaces
- 4 x USB 2.0 - header ¦ 2 x USB 3.2 Gen 1 - header ¦ 1 x audio - header
- Expansion / Connectivity - Power Connectors
- 24-pin main power connector, 4-pin ATX12V connector
- Expansion / Connectivity - Storage Interfaces
- SATA-600 -connectors: 4 x 7pin Serial ATA - RAID 0 / RAID 1 / RAID 10 ¦ SATA-600 / PCIe 3.0 -connectors: 1 x M.2
- Features - BIOS Features
- MSI ClickBIOS 5
- Features - Hardware Features
- MSI Audio Boost, MSI Core Boost, 2oz Copper PCB, Debug LED, Double ESD Protection
- General - Chipset Type
- AMD A520
- General - Compatible Processors
- Ryzen (supports 3rd Generation Ryzen and Ryzen 4000 G-Series)
- General - Max Processors Qty
- 1
- General - Processor Socket
- Socket AM4
- General - Product Type
- Motherboard - micro ATX
- Graphics - Max Allocated RAM Size
- 16 GB
- LAN - Network Controller
- Realtek RTL8111H
- LAN - Network Interfaces
- Gigabit Ethernet
- Miscellaneous - Cables Included
- 2 x Serial ATA cable
- Miscellaneous - Depth
- 20 cm
- Miscellaneous - Included Accessories
- Case badge, I/O back cover
- Miscellaneous - Software Included
- Drivers & Utilities
- Miscellaneous - Width
- 23.6 cm
- Supported RAM - Bus Clock
- 2400 MHz, 1866 MHz, 2133 MHz, 2800 MHz, 3000 MHz, 2666 MHz, 2933 MHz, 3200 MHz, 3066 MHz, 3466 MHz (O.C.), 3733 MHz (O.C.), 3600 MHz (O.C.), 3866 MHz (O.C.), 4000 MHz (O.C.), 4133 MHz (O.C.), 4400 MHz (O.C.), 4266 MHz (O.C.), 4600 MHz (O.C.)
- Supported RAM - Features
- Dual channel memory architecture, supported ECC modules operate in non-ECC mode, A-XMP support
- Supported RAM - Max Size
- 64 GB
- Supported RAM - Registered or Buffered
- Unbuffered
- Supported RAM - Supported RAM Integrity Check
- Non-ECC, ECC (operate in non-ECC mode)
- Supported RAM - Technology
- DDR4
