- Basic Specifications - EAN
- 4711387095119
- Basic Specifications - Form Factor
- ATX
- Basic Specifications - Manufacturer's Part Number
- 123603
- Basic Specifications - Max RAM Size
- 192 GB
- Basic Specifications - Processor Socket
- LGA1700
- External connectivity - Audio
- - Audio jacks x 5- Optical x 1 - S/PDIF in x 1
- External connectivity - LAN
- Realtek 2.5Gb Ethernet x 1
- External connectivity - Other external connections
- WiFi module x 1
- External connectivity - Video output
- - HDMI x 1- DisplayPort x 1
- General - Box contents
- - Asus TUF GAMING B760-PLUS LGA1700 Motherboard- WiFi antennas- SATA cables x 2- M.2 rubber package x 2- M.2 screw package- Support DVD- TUF certification card- User manual
- General - Colour
- Black
- General - Dimensions
- 25 x 244 x 305 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Software included
- - Armoury Crate- AI Suite 3- TUF GAMING CPU-Z- DTS Audio Processing- MyAsus- Norton Anti-virus software (Free Trial version)- WinRAR- ASUS EZ DIY
- General - Weight
- 1.15 kg
- Internal connectivity - BIOS
- - 128 Mb Flash ROM- UEFI AMI BIOS
- Internal connectivity - Buttons
- Power
- Internal connectivity - Case
- Power LED x 1
- Internal connectivity - Cooling
- - 4-pin CPU fan header x 1- 4-pin CPU OPT fan header x 1- 4-pin AIO Pump header x 1- 4-pin chassis fan headers x 4
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16) x 1- PCIe 3.0 (x16) (support x4 mode) x 1- PCIe 3.0 (x1) x 2
- Internal connectivity - Other internal connections
- - Thunderbolt 4 header x 1- Addressable Gen 2 headers x 3- Aura RGB header x 1- Clear CMOS header x 1- COM Port header x 1- Front Panel Audio header (AAFP) x 1- 20-3 pin System Panel header x 1
- Internal connectivity - Power
- - 24-pin EATX x 1- 8-pin ATX 12 V x 1- 4-pin ATX 12 V x 1
- Internal connectivity - Storage slots
- - SATA x 4 (6 GB/s)- M.2 x 3
- Internal connectivity - USB
- - USB Type-C x 2- USB 3.0 x 6- USB 2.0 x 3
- Overview - Chipset
- Intel B760
- Overview - Form factor
- ATX
- Overview - Memory slots
- 4 x DIMM (Max RAM: 192 GB)
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- - Windows 10 (64-bit)- Windows 11
- Overview - Processor models supported
- Intel® Core™ 14th & 13th Gen Processors, Intel® Core™ 12th Gen, Pentium® Gold and Celeron® Processors
- Overview - Socket
- Intel® LGA1700
