- Basic Specifications - EAN
- 4719331866587
- Basic Specifications - Manufacturer's Part Number
- 126180
- External connectivity - Audio
- Realtek Audio CODEC
- External connectivity - LAN
- Realtek GbE LAN chip
- External connectivity - Other external connections
- Antenna connectors (2T2R) x 2
- External connectivity - USB
- - USB Type-C x 1- USB 2.0 x 4
- External connectivity - Video output
- HDMI x 1
- General - Box contents
- - Gigabyte EAGLE B850 AM5 WIFI6E Motherboard- Manual- Quick Installation Guide- Antenna- SATA Cables x 2- G Connector x 1- M.2 screws- M.2 thick/thin rubber pads pack x 1
- General - Colour
- Black
- General - Dimensions
- 70 x 244 x 305 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Weight
- 1.31 kg
- Internal connectivity - BIOS
- UEFI AMI BIOS
- Internal connectivity - Buttons
- - Power button- Reset button- Q-Flash Plus
- Internal connectivity - Cooling
- - CPU fan header x 1- CPU fan/water cooling pump header x 1
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16) x 1- PCIe 3.0 (x16) x 3
- Internal connectivity - Other internal connections
- - Addressable RGB LED strip headers x 3- RGB LED strip header x 1
- Internal connectivity - Power
- - 24-pin ATX x 1- 8-pin ATX x 1- 4-pin ATX x 1
- Internal connectivity - Storage slots
- - SATA x 4 (6 GB/s)- M.2 x 3
- Overview - Chipset
- AMD B850
- Overview - Cooling features
- - Fan cooling - Liquid cooling
- Overview - Form factor
- ATX
- Overview - Memory slots
- 4 x DIMM (Max RAM: 256 GB)
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- Windows 10 or later
- Overview - Processor models supported
- - AMD Ryzen 9000 Series processors- AMD Ryzen 8000 Series processors- AMD Ryzen 7000 Series processors
- Overview - Socket
- AMD AM5
