- Basic Specifications - Docking Interface
- USB4 / Thunderbolt 4
- Basic Specifications - EAN
- 0732311013607
- Basic Specifications - Manufacturer Warranty
- 2-year warranty
- Basic Specifications - Manufacturer's Part Number
- ECHO-DK20-T4
- Basic Specifications - Model
- Sonnet Echo 20 SuperDock
- Basic Specifications - Monitor Inputs
- Thunderbolt, HDMI
- Basic Specifications - Networking
- 2.5 Gigabit Ethernet
- Basic Specifications - Product Description
- Sonnet Echo 20 SuperDock - docking station - USB4 / Thunderbolt 4 - HDMI, Thunderbolt - 2.5GbE
- Basic Specifications - Product Type
- Docking Station
- Basic Specifications - Video Interfaces
- HDMI, Thunderbolt
- Expansion / Connectivity - Expansion Slots
- 1 (total) / 1 (free) x SD UHS-II Memory Card ¦ 1 M.2 SATA/NVMe SSD
- Expansion / Connectivity - Interfaces
- 2 x Thunderbolt 4 ¦ 4 x USB-C 3.2 Gen 2 - 24 pin USB-C ¦ 4 x USB-A 3.2 Gen2 - 4 pin USB Type A ¦ 1 x audio / video - HDMI - 19 pin HDMI Type A ¦ 1 x headphone/microphone combo jack - mini-phone 3.5 mm ¦ 2 x audio - line-out - RCA ¦ 1 x network - 2.5G Gigabit Ethernet - RJ-45 ¦ 1 x microphone - mini-phone 3.5 mm ¦ Thunderbolt 4 with Power Delivery (100W) - 24 pin USB-C
- General - Product Type
- Docking station
- Manufacturer Warranty - Service & Support
- Limited warranty - 2 years
- Miscellaneous - Cables Included
- 1 x Thunderbolt 4 cable - 70 cm
- Miscellaneous - Compliant Standards
- FCC, WEEE, UKCA, VCCI
- Miscellaneous - Features
- 100W power delivery, security lock slot (cable lock sold separately)
- Miscellaneous - Included Accessories
- ThunderLok 3 Thunderbolt connector retainer clip
- Miscellaneous - Security Slot Type
- Kensington security slot
- Networking - Data Link Protocol
- 2.5 Gigabit Ethernet
- Video - Max Resolution Details
- 8K - 60 Hz
