- Basic Specifications - EAN
- 4719331872793
- Basic Specifications - Manufacturer's Part Number
- 127358
- External connectivity - Audio
- - 3.5 mm jacks x 3- S/PDIF Out
- External connectivity - LAN
- Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
- External connectivity - Other external connections
- - USB 2.0/1.1 ports x 2- PS/2 keyboard/mouse port x 1- D-Sub port x 1- USB 3.2 Gen 1 port x 3- RJ-45 port x 1
- External connectivity - USB
- - USB 3.0 x 3- USB 2.0 x 6
- External connectivity - Video output
- - HDMI x 1- DisplayPort x 2
- General - Box contents
- - Gigabyte B760M DS3H LGA1700 GEN5 Motherboard- SATA cables x 2- I/O Shield- Pack of M.2 thick/thin rubber pads x 1- Antenna x 1- User manual- Quick installation guide
- General - Colour
- Black
- General - Dimensions
- 70 x 244 x 244 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Weight
- 1 kg
- Internal connectivity - BIOS
- - 128 Mbit flash - UEFI AMI BIOS- PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
- Internal connectivity - Buttons
- - Q-Flash Plus- Reset- Clear CMOS
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16) x 1 - PCIe 3.0 (x1) x 2
- Internal connectivity - Power
- - 24-pin ATX x 1- 8-pin ATX x 1
- Internal connectivity - Sensors
- - Voltage detection- Temperature detection- Fan speed detection- Water cooling flow rate- Fan fail warning
- Internal connectivity - Storage slots
- - SATA x 4 (6 GB/s)- M.2 x 3
- Overview - Chipset
- Intel® B760 Express
- Overview - Cooling features
- Comprehensive Thermal
- Overview - Form factor
- Micro ATX
- Overview - Memory slots
- 4 x DIMM (Max RAM: 256 GB)
- Overview - Memory standard
- DDR5
- Overview - Processor models supported
- Intel® Core™, Pentium® Gold and Celeron® Processors
- Overview - Socket
- Intel® LGA1700
