- Basic Specifications - Capacity
- MAC addresses: 32000 ¦ Jumbo frame size: 10
- Basic Specifications - Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ap, IEEE 802.3bz
- Basic Specifications - Device Type
- Switch - 8 ports
- Basic Specifications - Dimensions (WxDxH)
- 29.4 cm x 18 cm x 4.4 cm
- Basic Specifications - EAN
- 6935364030926
- Basic Specifications - Enclosure Type
- Rack-mountable
- Basic Specifications - Features
- Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, DSCP based QoS
- Basic Specifications - Manufacturer's Part Number
- TL-SX1008
- Basic Specifications - Model
- TP-Link TL-SX1008 V1
- Basic Specifications - Performance
- Bandwidth: 160 Gbps ¦ Packet buffer size: 2 Mbps ¦ Packet transfer capability: 119 Mpps
- Basic Specifications - Power
- (50/60 Hz)
- Basic Specifications - Product Description
- TP-Link TL-SX1008 V1 - switch - 8 ports - rack-mountable
- Basic Specifications - Subtype
- Gigabit Ethernet
- Dimensions & Weight - Depth
- 18 cm
- Dimensions & Weight - Height
- 4.4 cm
- Dimensions & Weight - Width
- 29.4 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 90% (non-condensing)
- Environmental Parameters - Humidity Range Storage
- 5 - 90% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 50 °C
- Environmental Parameters - Max Storage Temperature
- 70 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Environmental Parameters - Min Storage Temperature
- -40 °C
- Expansion / Connectivity - Interfaces
- 8 x 1000Base-T RJ-45
- General - Capacity
- MAC addresses: 32000 ¦ Jumbo frame size: 10
- General - Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ap, IEEE 802.3bz
- General - Device Type
- Switch - 8 ports
- General - Enclosure Type
- Desktop, rack-mountable
- General - Features
- Flow control, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, DSCP based QoS
- General - Performance
- Bandwidth: 160 Gbps ¦ Packet buffer size: 2 Mbps ¦ Packet transfer capability: 119 Mpps
- General - Status Indicators
- Port status, system, link/activity
- General - Subtype
- Gigabit Ethernet
- Miscellaneous - Compliant Standards
- Plug and Play, FCC, RoHS
- Miscellaneous - Included Accessories
- Rubber feet
- Power - Power Consumption Operational
- 31.2 Watt
- Power - Power Device
- External power adapter
- Power - Power Provided
- AC 100-240 V - 0.8 A
- Power - Voltage Required
- (50/60 Hz)
