- Basic Specifications - EAN
- 4711387301777
- Basic Specifications - Form Factor
- Micro ATX
- Basic Specifications - Manufacturer's Part Number
- 123873
- Basic Specifications - Max RAM Size
- 96 GB
- Basic Specifications - Processor Socket
- LGA1700
- External connectivity - Audio
- 3.5 mm jack x 3
- External connectivity - LAN
- Intel® 1Gb Ethernet x 1
- External connectivity - Other external connections
- - WiFi module- PS/2 Keyboard (purple) port x 1- PS/2 Mouse (green) port x 1
- External connectivity - USB
- - USB Type-C x 1- USB 3.2 x 3- USB 2.0 x 6
- External connectivity - Video output
- - HDMI x 1- DisplayPort x 1
- General - Box contents
- - ASUS PRIME H610M-A WIFI LGA1700 Motherboard- Cables- SATA 6Gb/s cables x 2- ASUS Wi-Fi moving antennas x 1- I/O Shield x 11 x Screw package for M.2 SSDDocumentation1 x User guide"
- General - Colour
- Black
- General - Dimensions
- 25 x 216 x 244 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- General - Software included
- - ASUS Exclusive Software- Armoury Crate- Aura Creator- Aura Sync- Fan Xpert 2+- Two-Way AI Noise Cancellation- AI Suite 3- Performance And Power Saving Utility- TurboV EVO- EPU- DIGI+ VRM- PC Cleaner- ASUS CPU-Z- Norton 360 for Deluxe (60 Days Free Trial)- WinRAR- UEFI BIOS- ASUS EZ DIY- ASUS CrashFree BIOS 3- ASUS EZ Flash 3- ASUS UEFI BIOS EZ Mode
- General - Weight
- 551 g
- Internal connectivity - BIOS
- - UEFI AMI BIOS- 128 Mb Flash ROM
- Internal connectivity - Buttons
- Power
- Internal connectivity - Case
- Power LED x 1
- Internal connectivity - Cooling
- - CPU fan 4-pin x 1- 4-pin Chassis Fan headers x 2
- Internal connectivity - Expansion slots
- - PCIe 4.0 (x16) x 1- PCIe 3.0 (x1) x 1
- Internal connectivity - Other internal connections
- - Addressable Gen 2 headers x 3- Aura RGB header x 1- Clear CMOS header x 1- COM Port header x 1- Front Panel Audio header (AAFP) x 1- S/PDIF Out header x 1- Speaker header x 1- SPI TPM header (14-1pin) x 1- 10-1 pin System Panel header x 1
- Internal connectivity - Power
- - 24-pin EATX x 1- 8-pin ATX x 1
- Internal connectivity - Storage slots
- - SATA x 4 (6 GB/s)- M.2 x 2
- Internal connectivity - USB
- - USB 3.2 x 1- USB 2.0 x 2
- Overview - Chipset
- Intel® Z790
- Overview - Cooling features
- Fan cooling
- Overview - Form factor
- microATX
- Overview - Memory slots
- 2 x DIMM (Max RAM: 96 GB)
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- - Windows 10 (64-bit)- Windows 11
- Overview - Processor models supported
- - 13th Gen Intel® Core™ processors- 12th Gen Intel® Core™ processors- Intel® Pentium® Gold processors- Intel® Celeron® processors
- Overview - Socket
- Intel® LGA1700
