- Basic Specifications - Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at
- Basic Specifications - Device Type
- Switch - 26 ports - unmanaged
- Basic Specifications - Dimensions (WxDxH)
- 25.04 cm x 44 cm x 4.4 cm
- Basic Specifications - EAN
- 0790069426667
- Basic Specifications - Enclosure Type
- Rack-mountable 1U
- Basic Specifications - Features
- Flow control, Energy Efficient Ethernet, auto-uplink (auto MDI/MDI-X), store and forward
- Basic Specifications - MAC Address Table Size
- 8K entries
- Basic Specifications - Manufacturer's Part Number
- DGS-1026MP
- Basic Specifications - Model
- D-Link DGS 1026MP
- Basic Specifications - Performance
- Switching capacity: 52 Gbps ¦ Forwarding performance (64-byte packet size): 38.69 Mpps
- Basic Specifications - PoE Budget
- 370 W
- Basic Specifications - Ports
- 24 x 10/100/1000 (PoE) + 2 x combo Gigabit SFP
- Basic Specifications - Power
- AC 120/230 V (50/60 Hz)
- Basic Specifications - Power Over Ethernet (PoE)
- PoE
- Basic Specifications - Product Description
- D-Link DGS 1026MP - switch - 26 ports - unmanaged - rack-mountable
- Basic Specifications - Subtype
- Gigabit Ethernet
- Basic Specifications - Weight
- 3.1 kg
- Dimensions & Weight - Depth
- 44 cm
- Dimensions & Weight - Height
- 4.4 cm
- Dimensions & Weight - Weight
- 3.1 kg
- Dimensions & Weight - Width
- 25.04 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 90% (non-condensing)
- Environmental Parameters - Humidity Range Storage
- 5 - 95% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 50 °C
- Environmental Parameters - Max Storage Temperature
- 70 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Environmental Parameters - Min Storage Temperature
- -40 °C
- Expansion / Connectivity - Interfaces
- 24 x 1000Base-T RJ-45 PoE - 30 W ¦ 2 x 1000Base-T RJ-45 ¦ 2 x Gigabit LAN SFP
- General - Compliant Standards
- IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3x, IEEE 802.3z, IEEE 802.3af, IEEE 802.3at
- General - Device Type
- Switch - 26 ports - unmanaged
- General - Enclosure Type
- Rack-mountable, desktop 1U
- General - Features
- Flow control, Energy Efficient Ethernet, auto-uplink (auto MDI/MDI-X), store and forward
- General - MAC Address Table Size
- 8K entries
- General - Performance
- Switching capacity: 52 Gbps ¦ Forwarding performance (64-byte packet size): 38.69 Mpps
- General - PoE Budget
- 370 W
- General - Ports
- 24 x 10/100/1000 (PoE) + 2 x combo Gigabit SFP
- General - Power Over Ethernet (PoE)
- PoE
- General - Status Indicators
- Fail, link/activity, PoE, port transmission speed, power
- General - Subtype
- Gigabit Ethernet
- Miscellaneous - Compliant Standards
- BSMI, CCC, EN 60950-1, FCC Class A certified, IEC 60950-1, RCM, RoHS, UL 60950-1, VCCI
- Miscellaneous - MTBF
- 205,975 hours
- Miscellaneous - Rack Mounting Kit
- Included
- Power - Power Device
- Internal power supply
- Power - Voltage Required
- AC 120/230 V (50/60 Hz)
