- Basic Specifications - Capacity
- Packet buffer size: 4.1 Mbit
- Basic Specifications - Compliant Standards
- IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
- Basic Specifications - Device Type
- Switch - 26 ports - unmanaged
- Basic Specifications - Dimensions (WxDxH)
- 44 cm x 18 cm x 4.4 cm
- Basic Specifications - EAN
- 6935364089450
- Basic Specifications - Enclosure Type
- Rack-mountable 1U
- Basic Specifications - Features
- Flow control, PoE, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, PoE+, 2 fans, MAC address learning, MAC address aging, priority mode, extend mode, security slot (Kensington security lock compatible)
- Basic Specifications - Jumbo Frame Support
- 10KB
- Basic Specifications - MAC Address Table Size
- 8K entries
- Basic Specifications - Manufacturer's Part Number
- TL-SL1226P
- Basic Specifications - Model
- TP-Link TL-SL1226P
- Basic Specifications - Performance
- Switching capacity: 8.8 Gbps ¦ Packet forwarding rate: 6.54 Mpps
- Basic Specifications - PoE Budget
- 250 W
- Basic Specifications - Ports
- 24 x 10/100 (PoE+) + 2 x 10/100/1000 + 2 x combo Gigabit SFP
- Basic Specifications - Power
- AC 120/230 V (50/60 Hz)
- Basic Specifications - Power Over Ethernet (PoE)
- PoE+
- Basic Specifications - Product Description
- TP-Link TL-SL1226P - switch - 26 ports - unmanaged - rack-mountable
- Basic Specifications - Subtype
- Fast Ethernet
- Dimensions & Weight - Depth
- 18 cm
- Dimensions & Weight - Height
- 4.4 cm
- Dimensions & Weight - Width
- 44 cm
- Environmental Parameters - Humidity Range Operating
- 10 - 90% (non-condensing)
- Environmental Parameters - Humidity Range Storage
- 5 - 90% (non-condensing)
- Environmental Parameters - Max Operating Temperature
- 50 °C
- Environmental Parameters - Max Storage Temperature
- 70 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Environmental Parameters - Min Storage Temperature
- -40 °C
- Expansion / Connectivity - Interfaces
- 24 x 100Base-TX RJ-45 PoE+ - 30 W ¦ 2 x 1000Base-T RJ-45 ¦ 2 x 1000Base-X SFP
- General - Capacity
- Packet buffer size: 4.1 Mbit
- General - Compliant Standards
- IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
- General - Device Type
- Switch - 26 ports - unmanaged
- General - Enclosure Type
- Desktop, rack-mountable 1U
- General - Features
- Flow control, PoE, auto-negotiation, auto-uplink (auto MDI/MDI-X), store and forward, PoE+, 2 fans, MAC address learning, MAC address aging, priority mode, extend mode, security slot (Kensington security lock compatible)
- General - Jumbo Frame Support
- 10KB
- General - MAC Address Table Size
- 8K entries
- General - Performance
- Switching capacity: 8.8 Gbps ¦ Packet forwarding rate: 6.54 Mpps
- General - PoE Budget
- 250 W
- General - Ports
- 24 x 10/100 (PoE+) + 2 x 10/100/1000 + 2 x combo Gigabit SFP
- General - Power Over Ethernet (PoE)
- PoE+
- General - Status Indicators
- Power, 100M device connected, 1000M device connected, PoE, link/activity, PoE max
- General - Subtype
- Fast Ethernet
- Miscellaneous - Compliant Standards
- Plug and Play, FCC, RoHS
- Miscellaneous - Rack Mounting Kit
- Included
- Power - Power Consumption Operational
- 294 Watt
- Power - Power Device
- Internal power supply
- Power - Voltage Required
- AC 120/230 V (50/60 Hz)
