- Basic Specifications - EAN
- 4711377286572
- Basic Specifications - Manufacturer's Part Number
- 126149
- External connectivity - Audio
- - Realtek® ALC897 Codec- 7.1-Channel High-Definition Audio
- External connectivity - LAN
- - Intel® Wi-Fi 7- Bluetooth 5.4
- External connectivity - USB
- - USB Type-A (10Gbps) x 2- USB Type-A (5Gbps) x 6- USB Type-C (10 Gbps) x 1- USB 2.0 x 8
- External connectivity - Video output
- - HDMI 2.1 x 1- DisplayPort 1.4 x 1
- General - Box contents
- - MSI PRO B860-P WIFI LGA1851 Motherboard- SATA Cable x 1- EZ M.2 Clip x 3- EZ M.2 Clip remover x 1- EZ Wi-Fi Antenna- Quick Installation Guide
- General - Colour
- Black
- General - Dimensions
- 73 x 243 x 304 mm (H x W x D)
- General - Manufacturer’s guarantee
- 3 years
- Internal connectivity - BIOS
- Flash BIOS
- Internal connectivity - Buttons
- - Power button- Clear CMOS Button
- Internal connectivity - Cooling
- - CPU fan x 1- Combo fan x 1- System fan x 4
- Internal connectivity - Expansion slots
- - PCIe 5.0 (x16 slot) x 1- PCIe 4.0 (x16 slot) x 1- PCIe 4.0 (x1 slot) x 2
- Internal connectivity - Other internal connections
- - Thunderbolt5 card connector x 1- CPU Fan x 1- Combo Fan x 1- System Fan x 4- Front Panel (JFP) x 2- Chassis Intrusion (JCI) x 1- Front Audio (JAUD) x 1- Com Port (JCOM) x 1- Tuning Controller connector (JDASH) x 1- Addressable V2 RGB LED connector (JARGB_V2) x 2- RGB LED connector (JRGB) x 1- TPM pin header (Support TPM 2.0) x 1
- Internal connectivity - Power
- - Power connector (ATX_PWR) x 1- Power connector (CPU_PWR) x 2- Power connector (PCIE_PWR 8pin) x 1
- Internal connectivity - Storage slots
- - SATA x 4 (6 GB/s) - M.2 x 3 (64 GB/s)
- Overview - Chipset
- Intel® B860
- Overview - Cooling features
- - Frozr AI cooling- Fan cooling
- Overview - Form factor
- ATX
- Overview - Memory slots
- 4 x UDIMM (Max RAM: 256 GB)
- Overview - Memory standard
- DDR5
- Overview - Operating systems supported
- Windows 11 or later
- Overview - Processor models supported
- Intel® Core™ Ultra Processors (Series 2)
- Overview - Socket
- Intel® LGA1851
