- Basic Specifications - Device Type
- NAS server
- Basic Specifications - Dimensions (WxDxH)
- 16.8 cm x 23 cm x 18.4 cm
- Basic Specifications - EAN
- 4711174724918
- Basic Specifications - Host Connectivity
- Gigabit Ethernet
- Basic Specifications - Installed Devices / Modules Qty
- 0 (installed) / 4 (max)
- Basic Specifications - IP Cameras Supported
- 30
- Basic Specifications - Manufacturer Warranty
- 2-year warranty
- Basic Specifications - Manufacturer's Part Number
- DS423
- Basic Specifications - Model
- Synology Disk Station DS423
- Basic Specifications - Networking
- 10Mb LAN, 100Mb LAN, 1GbE
- Basic Specifications - Power
- AC 100-240 V (50/60 Hz)
- Basic Specifications - Processor
- 1 x Realtek Semiconductor RTD1619B 1.7 GHz (Quad-Core)
- Basic Specifications - Product Description
- Synology Disk Station DS423 - NAS server
- Basic Specifications - RAM
- 2 GB
- Basic Specifications - Storage Controller
- RAID SATA 6Gb/s RAID JBOD, 0, 1, 5, 6, 10
- Basic Specifications - Storage Operating System
- Synology DiskStation Manager
- Basic Specifications - Weight
- 2.21 kg ()
- Environmental Parameters - Humidity Range Operating
- 5 - 95% RH
- Environmental Parameters - Max Operating Temperature
- 40 °C
- Environmental Parameters - Min Operating Temperature
- 0 °C
- Environmental Parameters - Sound Emission
- 20.6 dBA
- Expansion / Connectivity - Expansion Bays
- 4 (total) / 4 (free) x hot-swap - 2.5" / 3.5"
- Expansion / Connectivity - Interfaces
- 2 x USB 3.2 Gen 1 - Type A ¦ 2 x Ethernet 1000Base-T - RJ-45
- General - Built-in Devices
- 2 x fans
- General - Depth
- 23 cm
- General - Device Type
- NAS server
- General - Height
- 18.4 cm
- General - Host Connectivity
- Gigabit Ethernet
- General - Installed Devices / Modules Qty
- 0 (installed) / 4 (max)
- General - Total Storage Capacity
- 0 GB
- General - Weight
- 2.21 kg ()
- General - Width
- 16.8 cm
- Manufacturer Warranty - Service & Support
- Limited warranty - 2 years
- Miscellaneous - Cables Included
- 2 x network cable
- Miscellaneous - Compliant Standards
- FCC, BSMI, VCCI, RCM, UKCA, EAC, CCC, KC, RoHS
- Miscellaneous - Features
- Power recovery, scheduled power on/off, security lock slot (cable lock sold separately)
- Miscellaneous - Included Accessories
- Accessory pack, power cable
- Miscellaneous - Security Slot Type
- Kensington security slot
- Networking - Data Link Protocol
- 10Mb LAN, 100Mb LAN, 1GbE
- Networking - Features
- Hardware encryption, Link Aggregation, failover protection, WOL, WOW, SSD trim, Synology Hybrid RAID, RAID migration, NFS Kerberos authentication, Windows ACL, Syslog support, VPN Server, DLNA Media Server
- Networking - Network Services Compatibility
- Server Message Block (SMB), Apple File Protocol (AFP), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), FTP, Calendaring Extensions to WebDAV (CalDAV), Web-based Distributed Authoring and Versioning (WebDAV), Microsoft CIFS
- Networking - Remote Management Protocol
- HTTP, HTTPS, SNMP, LDAP
- Power - Power Consumption Operational
- 32.41 Watt
- Power - Power Consumption Stand by
- 4.97 Watt
- Power - Power Device
- External power adapter
- Power - Power Provided
- 90 Watt
- Power - Voltage Required
- AC 100-240 V (50/60 Hz)
- Processor / Memory - Max Supported Qty
- 1
- Processor / Memory - Number of Cores
- Quad-Core
- Processor / Memory - Processors Installed
- 1 x Realtek Semiconductor RTD1619B 1.7 GHz
- Processor / Memory - RAM
- 2 GB DDR4
- Security DVR - Compression Format
- H.264, H.265
- Security DVR - Image Resolution
- 1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160
- Security DVR - IP Cameras Supported
- 30
- Software / System Requirements - Storage Operating System
- Synology DiskStation Manager
- Storage Controller - Interface Type
- SATA 6Gb/s
- Storage Controller - RAID Level
- JBOD, RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
- Storage Controller - Type
- RAID
